Omron NB10W-TW01B-V1 — 10.1" NB HMI, WSVGA, Ethernet

SKU: NB10W-TW01B-V1

USD 305.00

Omron NB10W-TW01B-V1 10.1-inch WSVGA (1024 x 600) NB-V1 touch HMI, Ethernet + USB, IP65 front. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NB10W-TW01B-V1 is a 10.1-inch NB-V1 series touch screen HMI, manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the Sysmac Studio or NB-Designer project file on a USB drive included.

The panel is a WSVGA TFT LCD at 1024 x 600 pixels with 65536 colours and a white LED backlight rated 50 kh at 25 degC. Touch is analog resistive with a 1 million operation life. Built-in ports are Ethernet 10/100 Base-T, USB host, USB slave, 2 x RS-232C and 1 x RS-422A / RS-485. Programming runs in NB-Designer on a Windows PC.

Supply is 24 VDC at 20.4 to 27.6 VDC and power consumption is 14 W. Front face is IP65. Panel cutout is 258 x 200 mm and depth is 54 mm. The NB10W-TW01B is the V0 model at 800 x 480; the NB10W-TW01B-V1 is the current-production replacement. For a smaller V1 panel, pick the NB7W-TW01B-V1.

Key Features

  • 10.1-inch TFT colour LCD, WSVGA 1024 x 600 resolution, 65536 colours, 50 kh LED backlight
  • Analog resistive touch, 128 MB memory, Ethernet 10/100 + USB host + USB slave + 2 x RS-232C + RS-422A/485
  • 24 VDC supply (20.4 to 27.6 VDC), 14 W power consumption, IP65 front, portrait or landscape mounting
  • Programmed in NB-Designer; connects to CP1, CJ1, CJ2, NJ, NX, Sysmac and third-party PLCs over Ethernet or serial
  • SKU: NB10W-TW01B-V1
  • Series: Omron NB-V1 touch screen HMI
  • Voltage: 24 VDC

Best-Fit Applications

  • Operator panel on a packaging line where the 10.1-inch display shows recipe set and trend graphs over EtherNet/IP to a CP1L or NJ PLC
  • Machine overview screen on a filling station where the 2 x RS-232C ports connect to a CP1H and a serial barcode scanner at once
  • Spare panel on a Sysmac NJ cell where the NB-V1 WSVGA resolution matches the larger NA-series HMI next to it

Buying Checklist

  • Pick the NB10W-TW01B-V1 for a 10.1-inch NB-V1 touch HMI with 1024 x 600 WSVGA resolution, Ethernet, and IP65 front.
  • Pick the NB10W-TW01B instead when the panel must match an existing V0 installation at 800 x 480 resolution.
  • Pick the NB7W-TW01B-V1 instead when the cabinet only has room for a 7-inch panel and you want the V1 CPU upgrade.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NB-V1 touch screen HMI
Model / SKU NB10W-TW01B-V1
Display 10.1-inch TFT colour LCD, WSVGA 1024 x 600 pixels, 65536 colours
Backlight White LED, 50000 hours at 25 degC
Touch Panel Analog resistive, 1 million operations
Memory 128 MB internal
Communication Ports Ethernet 10/100 Base-T; USB host (type A); USB slave (type B); 2 x RS-232C; RS-422A / RS-485
Supply Voltage 24 VDC, 20.4 to 27.6 VDC
Power Consumption 14 W max
Front Protection IP65
Dimensions / Cutout 268.8 (W) x 210.8 (H) x 54 (D) mm; cutout 258 x 200 mm; 1465 g

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NB10W-TW01B-V1

What is the Omron NB10W-TW01B-V1 used for?
It is the operator panel for a small or mid-size machine. The 10.1-inch touch screen runs the NB-Designer project, talks to a CP, CJ, NJ or NX PLC over Ethernet or serial, and shows process graphics, alarms and recipe data.
What is the difference between NB10W-TW01B-V1 and NB10W-TW01B?
The V1 has a 1024 x 600 WSVGA display and a faster CPU. The V0 (NB10W-TW01B without -V1) is 800 x 480 WVGA. The V1 is the current-production replacement; the V0 is kept in the catalogue for spare replacement of existing panels.
Does the NB10W-TW01B-V1 connect to a Sysmac NJ or NX PLC?
Yes. It has Ethernet and either RS-232C or RS-422A/485 on board. Use Ethernet and the built-in NB-Designer driver for an NJ / NX101 / NX102 / NX502 CPU; the NB-Designer setup manual lists the Ethernet and serial drivers.
What programming software does the NB10W-TW01B-V1 use?
NB-Designer, free to download from the Omron NB family download page. The project downloads to the panel over Ethernet or USB. Sysmac Studio is not required.
What is the IP rating of the NB10W-TW01B-V1 front face?
IP65 when the panel is correctly mounted in a cutout with the supplied gasket. The rear of the panel is Type 1 indoor enclosure.
