Omron NB7W-TW01B — front face showing the 7-inch WVGA TFT colour display with a sample operator screen, the analog resistive touch panel, and the 202 x 148 mm black bezel with the IP65 front seal

Omron NB7W-TW01B — 7" WVGA Touch HMI, Ethernet + USB

SKU: NB7W-TW01B

USD 185.00

7-inch WVGA 800 x 480 TFT touch HMI, Ethernet + 2 USB + 2 serial ports, IP65 front, 24 VDC.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NB7W-TW01B is a 7-inch WVGA touch HMI from the NB series It is manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the NB-Designer project file on a USB drive included. The screen is a 7-inch TFT colour LCD at 800 x 480 pixels with 65,536 colours and a 50,000-hour LED backlight. It carries 128 MB of internal memory, Ethernet 10/100 BASE-T, one USB Host and one USB Slave, plus two serial ports on D-Sub 9-pin connectors (COM1 RS-232C and COM2 RS-232C / 422A / 485). For a serial-only sibling without Ethernet, pick the NB7W-TW00B. Key specs: Display Size / Type 7-inch TFT colour LCD; Resolution / Colors 800 x 480 pixels (WVGA); 65,536 colours; Backlight White LED, 50,000 hr typical at 25 degC; Touch Panel Analog resistive, 1024 x 1024 resolution, 1 million touches min.; Internal Memory 128 MB (including system area); Ethernet / USB 1 port 10/100 BASE-T; 1 USB Host (type A, 5 V / 150 mA); 1 USB Slave (type B); Serial Ports COM1 RS-232C (D-Sub 9-pin, 15 m); COM2 RS-232C / 422A / 485 (D-Sub 9-pin, 15 m / 500.

Key Features

  • 7-inch WVGA TFT colour LCD, 800 x 480 pixels, 65,536 colours, 50,000 hr LED backlight
  • Ethernet 10/100 BASE-T plus USB Host (type A) and USB Slave (type B)
  • Two serial ports: COM1 RS-232C and COM2 RS-232C / RS-422A / RS-485 (not isolated)
  • IP65 front face, 202 x 148 mm bezel, 191 x 137 mm cutout, 46 mm depth, 24 VDC supply
  • SKU: NB7W-TW01B
  • Series: Omron NB series touch HMI (NB7W family)

Best-Fit Applications

  • Operator panel on a CP1L-EM30DT-D filling machine where the 7-inch WVGA screen fits the recipes, alarms, and trend page on a single screen
  • Remote status display for a boiler skid, talking Modbus TCP over Ethernet to an NJ101-1000 and showing the live process values and faults
  • Spare replacement on a packaging line where the existing NB7W-TW01B project downloads over the rear USB Slave port and runs without re-engineering

Buying Checklist

  • Pick the NB7W-TW01B for a 7-inch NB-series touch HMI with Ethernet, USB Host, and two serial ports on a 191 x 137 mm panel cutout.
  • Pick the NB7W-TW00B instead when the panel only needs serial communication and Ethernet is not required on the operator station.
  • Pick the NB10W-TW01B instead when a 10.1-inch WVGA screen is needed in the same NB-series tool chain.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NB series touch HMI (NB7W family)
Model / SKU NB7W-TW01B
Display Size / Type 7-inch TFT colour LCD
Resolution / Colors 800 x 480 pixels (WVGA); 65,536 colours
Backlight White LED, 50,000 hr typical at 25 degC
Touch Panel Analog resistive, 1024 x 1024 resolution, 1 million touches min.
Internal Memory 128 MB (including system area)
Ethernet / USB 1 port 10/100 BASE-T; 1 USB Host (type A, 5 V / 150 mA); 1 USB Slave (type B)
Serial Ports COM1 RS-232C (D-Sub 9-pin, 15 m); COM2 RS-232C / 422A / 485 (D-Sub 9-pin, 15 m / 500 m, not isolated)
Bezel / Cutout / Depth 202 x 148 mm bezel; cutout 191 x 137 mm; 46 mm depth
Supply / Front / Weight 24 VDC (20.4 to 27.6 VDC), 7 W typical; IP65 front; 1.0 kg

FAQ for NB7W-TW01B

What is the Omron NB7W-TW01B used for?
It is a 7-inch operator touch panel for small to mid-sized Omron PLCs and third-party Modbus devices. The Ethernet port handles TCP/IP traffic to NJ / NJ-series PLCs; the two serial ports handle Host Link or Modbus RTU to CP1 and CJ-series CPUs.
NB7W-TW01B vs NB7W-TW00B — what is the difference?
Ethernet. The TW01B adds a 10/100 BASE-T Ethernet port for TCP/IP and remote HMI access. The TW00B relies on the two serial ports plus USB only and has no Ethernet. Both share the same 7-inch WVGA screen and NB-Designer tool chain.
What software programs the NB7W-TW01B?
NB-Designer, version 1.10 or higher. Projects download to the panel over the rear USB Slave port. The 128 MB internal flash holds both the project file and runtime data such as recipes and alarm logs.
What replaces the NB7W-TW01B?
Production of the original NB7W-TW01B ended on 31 March 2025. Omron's designated replacement is the NB7W-TW01B-V1, the same panel with V1 hardware. The NA series is a different product line programmed in Sysmac Studio and is not a drop-in replacement.
