Omron NS10-TV01B-V2 — 10.4" HMI TFT Ethernet
SKU: NS10-TV01B-V2USD 720.00
Omron NS10-TV01B-V2 is a 10.4-inch TFT NS-series HMI with Ethernet, dual RS-232C ports, 60MB screen memory, and 32K colors in a black case — connects to CS/CJ/CP/NX PLCs.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The NS10-TV01B-V2 is a 10.4-inch TFT color touchscreen in Omron's NS-series HMI line. The 'V2' suffix identifies the 2nd-generation NS with refined firmware, improved contrast, and updated USB handling. The 'B' suffix is the black case (an ivory/white version, NS10-TV01-V2, also exists — pick by panel aesthetic). In a typical machine, the NS10 acts as the operator interface: shows process status, accepts operator inputs, displays alarms, logs production counts. The 10.4-inch screen with 640x480 VGA resolution is a sweet spot for OEM machines — large enough to show multiple data fields and a trend graph, small enough to fit in a 16-inch-deep swing-arm panel. Connectivity is the NS10's main strength: Ethernet (10/100 Base-T) for connecting to a modern PLC (NX102, NJ501, CP1L with Ethernet option), 2x RS-232C for legacy PLC serial (CP1L, CJ1, C200H), USB Slave for project transfer from CX-Designer, and USB Master for connecting a USB memory stick for recipe transfer or screen data logging. The Ethernet port supports both FINS/UDP and the higher-level FINS/TCP protocol for Omron PLCs, plus Modbus/TCP for non-Omron controllers. The 60 MB screen memory is generous for a 10.4-inch HMI: you can store 500+ screens with images, hundreds of alarm messages, recipe data with hundreds of parameters, and data logging for days of operation. For comparison, the smaller NS5 (5.7-inch) has 20 MB, and the larger NS12 (12.1-inch) also has 60 MB. Programming is via Omron's CX-Designer software (free, runs on Windows). Projects transfer over USB, Ethernet, or serial. The NS10-V2 is fully compatible with NS10-V1 projects — old screens open in the new firmware without conversion. For new projects, consider the NB-series (NB10W-TW01B) which uses NB-Designer and has a more modern interface. The NS10 is the value pick for legacy NS compatibility. Common use: machine builder who standardised on CX-Designer across many product lines, or end-user replacing a failed NS10 with the same form factor. For new OEM designs, the NB or NA series is now the recommended path — the NS is in long-term support but not the newest product line.
Key Features
- 10.4-inch TFT color LCD display
- High resolution for detailed graphics
- Touch screen operation
- Ethernet connectivity built-in
- Multiple serial ports RS-232C RS-422/485
- NS-Designer software for screen development
- Large built-in memory for complex applications
- IP65 front panel protection
- SKU: NS10-TV01B-V2
- Series: NS10
Best-Fit Applications
- Operator interface for packaging machine with recipe selection, production count display, and alarm history
- Trend graph display for process temperature/pressure monitoring in food and beverage production
- Maintenance screen showing I/O status, fault logs, and runtime hours for OEM machine builders
- Multi-language HMI for export equipment requiring 4-5 language support without code changes
Buying Checklist
- 60MB screen memory supports complex screens with images, alarms, recipes, and data logs
- Ethernet + 2x RS-232C + USB Host/Slave covers all common PLC connection paths
- V2 firmware with refined USB handling and improved display contrast over V1
- Black case suits modern OEM machine aesthetic; full CX-Designer programming environment
- Backwards compatible with V1 projects for spare-part replacement of legacy units
Technical Specifications
| Model | NS10-TV01B-V2 |
|---|---|
| Series | NS10 |
| Screen Size | 10.4 inch |
| Display Type | TFT Color LCD |
| Resolution | 640 x 480 pixels |
| Communication | Ethernet, 2x Serial |
| Supply Voltage | DC24V |
| Protection | IP65 front panel |
| Operating Temperature | 0 to +55°C |
Resources & Downloads
FAQ for NS10-TV01B-V2
What's the difference between NS10-TV01-V2 and NS10-TV01B-V2?
The B suffix = black case; no B = ivory/white case. Specs, electronics, firmware, and price are identical. Pick by panel aesthetic. Most modern OEM machines use the black case (B variant) for a contemporary look; food and pharmaceutical machines sometimes prefer ivory (lighter colour) for visibility in clean rooms.
Can NS10-TV01B-V2 connect to a non-Omron PLC?
Yes, via Modbus/TCP over Ethernet, or Modbus RTU over the RS-232C port. The NS also supports direct connection to Omron CP1, CJ1, CS1, NJ, NX PLCs via FINS/UDP or FINS/TCP. For Allen-Bradley, Siemens, or Mitsubishi, Modbus is the typical integration path; some third-party gateways add EtherNet/IP or PROFINET support at the cost of latency.
Can I use NS10 with the newer NB or NA series software?
No — NS uses CX-Designer, NB uses NB-Designer, NA uses Sysmac Studio. They are separate product lines with separate software. You cannot convert a CX-Designer project directly to NB-Designer; you would need to rebuild the screens. The NS, NB, and NA series can coexist on the same machine if you need different screen sizes.
What is the difference between NS10-V1 and NS10-V2?
V2 is the 2nd-generation NS series (2014+) with refined firmware, USB Host support, and improved display contrast. V1 (2004-2013) is the original NS. V2 is fully backwards compatible — V1 projects load and run on V2 hardware. V1 hardware is now in long-term support; V2 is current.
