Omron NS5-MQ00B-V2 — front view of the 5.7-inch HMI showing the QVGA 320 x 240 monochrome STN display, the resistive touch overlay, the Omron model label and the IP65F front seal

Omron NS5-MQ00B-V2 — HMI, 5.7-Inch STN Monochrome

SKU: NS5-MQ00B-V2

USD 425.00

Omron NS5-MQ00B-V2 5.7-inch STN monochrome HMI, 320x240, 2 RS-232C + USB, CX-Designer, IP65F. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NS5-MQ00B-V2 is a 5.7-inch monochrome STN programmable terminal from the NS5 family, manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the Sysmac Studio or NB-Designer project file on a USB drive included.

The QVGA 320 x 240 screen shows 16 grayscale gradations on a backlight whose type and service life we have not been able to confirm against Omron's published NS5-V2 table; check the datasheet for the MQ variant specifically. Touch is a 4-wire resistive panel. The unit runs on 24 VDC at 15 W max. Communication is 2 x RS-232C ports (Port A and Port B) and a USB 1.1 device port. A CompactFlash slot holds project backups and recipe data.

The front face is IP65F / NEMA Type 4. The body is 195 x 142 x 54 mm and weighs about 1 kg. Programming runs in CX-Designer under the CX-One suite. Project memory is 20 MB. For a colour STN version on the same 5.7-inch body, use the NS5-SQ10B-V2. For a 10.4-inch TFT panel, use the NS10-TV00B-V2.

Key Features

  • NS5-V2 5.7-inch STN monochrome programmable terminal, 320 x 240 QVGA, 16 grayscale
  • 2 x RS-232C ports (Port A / Port B), 1 x USB 1.1 device, CompactFlash slot
  • 24 VDC 15 W supply, IP65F front, 195 x 142 x 54 mm, 1 kg
  • CX-Designer programming under CX-One, 20 MB project memory
  • SKU: NS5-MQ00B-V2
  • Series: Omron NS-series programmable terminal (NS5-V2)
  • Voltage: 24 VDC

Best-Fit Applications

  • Operator panel on a CNC lathe where the 5.7-inch QVGA shows the spindle RPM and feed trend and the RS-232C port talks to a drive
  • Spare replacement on an existing NS5-V2 panel where the CompactFlash recipe card carries the old project over and the cutout matches the new unit
  • Standalone parameter page on a packaging machine where the IP65F front face handles daily washdown and the monochrome screen keeps the BOM cost down

Buying Checklist

  • Pick the NS5-MQ00B-V2 for a 5.7-inch monochrome STN HMI with 2 RS-232C ports and CX-Designer programming on the NS5-V2 platform.
  • Pick the NS5-SQ10B-V2 instead when the operator page needs a 5.7-inch colour STN display with RS-422A/485.
  • Pick the NS10-TV00B-V2 instead when the cabinet door has room for a 10.4-inch TFT panel.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NS-series programmable terminal (NS5-V2)
Model / SKU NS5-MQ00B-V2
Display 5.7-inch STN monochrome LCD, 320 x 240 QVGA, 16 grayscale
Backlight LED backlight (the CCFL-to-LED change came with the -V2 generation)
Touch Panel 4-wire resistive, 1 million touches
Supply Voltage 24 VDC (20.4 to 27.6 VDC), 15 W max
Communication Ports 2 x RS-232C (D-Sub 9 Port A and Port B), 1 x USB 1.1 device, CompactFlash slot
Project Memory 20 MB
Programming Software CX-Designer under CX-One
Front Protection IP65F / NEMA Type 4
Dimensions / Weight 195 (W) x 142 (H) x 54 (D) mm; 1 kg; 0 to 50 degC

FAQ for NS5-MQ00B-V2

What software programs the NS5-MQ00B-V2?
CX-Designer under the CX-One suite. The project supports Smart Active Parts for direct tag binding to Omron CP, CJ and CS-series PLCs over Host Link (RS-232C) or NT Link (1:1 / 1:N).
Does the NS5-MQ00B-V2 have Ethernet?
No. The -00B model has no Ethernet port. For an NS5 with Ethernet (EtherNet/IP or FINS), use the NS5-MQ01B-V2 or the colour NS5-SQ01B-V2.
Can I replace an NS5-MQ00B-V1 with the -V2 model?
Yes. The -V2 is a drop-in replacement for the -V1 on the same 195 x 142 mm cutout, with the same CX-Designer project. The new -V2 has an LED backlight and supports the latest CX-Designer version.
What CompactFlash cards fit the NS5-MQ00B-V2?
Any standard Type I CompactFlash card up to 2 GB. Use Omron HMC-AP001 or HMC-AP002 for verified industrial-grade cards. The card holds project backups, recipe data and the alarm log.
