Omron NS10-TV00B-V2 — PLC Controller
SKU: NS10-TV00B-V2USD 730.00
10.4-inch 640x480 TFT color touchscreen HMI, black bezel, no Ethernet (use TV01 for Ethernet), 32,768 colors, 60 MB memory, CX-Designer programming. Discontinued April 2022 — see NA5-9W001B-V1 or NA5-12W101B-V1.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The NS10-TV00B-V2 is a 10.4-inch TFT color touchscreen HMI from Omron's NS-series, built for legacy panels that talk to a CJ-series, CP1-series, or CS1 PLC over RS-232C / RS-422/485 serial only. The display is 640 × 480 pixels (VGA) with 32,768 colors, LED backlight rated for 50,000 hours to half-brightness, and a matrix-resistive analog touch overlay. The "-B" suffix means black bezel (the non-B variant NS10-TV00-V2 is ivory); the "TV00" means no built-in Ethernet (TV01 means Ethernet-equipped); the "V2" means the second-generation firmware with Smart Active Parts and improved Ladder Monitor. Power consumption is 25 W maximum from a 24 VDC supply. Project memory is 60 MB.
How NS10-TV00B-V2 differs from siblings
The NS10 family splits along four axes: bezel colour (-B = black, otherwise ivory), Ethernet (TV00 = none, TV01 = yes), firmware revision (V1 = legacy, V2 = current), and special suffix (-EC = enhanced communication). Concretely: NS10-TV00-V2 is the ivory TV00 sibling; NS10-TV01B-V2 is the black Ethernet-equipped sibling; NS10-TV01-V2 is the ivory Ethernet-equipped sibling; NS10-TV00B-ECV2 adds the enhanced-communication option (FINS routing, additional protocols). The NS10-TV00B-V2 (this SKU) is the right pick when your PLC is CP1L or CJ2M with no Ethernet/IP requirement and you want a black-bezel panel that visually matches modern machine designs.
NS10-V2 ports, programming, and integration
On the rear of the NS10-TV00B-V2 you'll find two D-sub 9-pin serial ports (port A: RS-232C only, port B: RS-232C or RS-422/485 selectable by switch) plus a USB Type-A host port (for USB memory stick project transfer and peripheral support) and a USB Type-B slave port (for direct PC connection from CX-Designer). The TV00 variant has no RJ-45 Ethernet connector — there is no TCP/IP communication available. For serial-only connections, the HMI can communicate with up to 16 host PLCs simultaneously using Host Link (SYSMAC WAY) protocol over serial, with auto-polling of allocated bit/word addresses every 100 ms or on screen event.
Discontinued April 2022 — what to use instead
The NS10-TV00B-V2 was discontinued by Omron in April 2022 (along with the entire NS-series V2 lineup). Service spares are still available from distributors and the unit remains fully supported for CX-Designer programming — but for new designs, the recommended replacement is the NA5-9W001B-V1 (9-inch WSVGA Sysmac-family panel for small-to-medium panels) or the NA5-12W101B-V1 (12.1-inch WXGA for larger HMI layouts). For budget-driven designs where Sysmac Studio integration is not required, the NB10W-TW01B (10.1-inch NB-series panel, 1,280 × 800 resolution, NB-Designer programming) is still in active production.
Key Features
- 10.4-inch TFT color LCD, 640 × 480 resolution, 32,768 colors
- Black bezel, matches modern machine aesthetics
- Matrix-resistive analog touch overlay, 25 ms response
- No built-in Ethernet — serial-only communication
- 60 MB project memory with CompactFlash and USB memory support
- 2 × RS-232C serial ports + 1 × RS-422/485
- USB Type-A host + USB Type-B slave ports
- CX-Designer programming software
- SKU: NS10-TV00B-V2
- Series: NS-series V2 Programmable Terminals (discontinued)
- Voltage: 24 VDC
Best-Fit Applications
- Operator interface for a CJ2M-CPU33 controlled packaging line communicating over Host Link serial
- CP1L-controlled OEM machine HMI where Ethernet is not required and cost is the driver
- Black-bezel operator panel mounted on a machine door to match modern industrial design language
- Legacy panel replacement for an existing NS10 installation maintaining serial Host Link communication
Buying Checklist
- Pick NS10-TV00B-V2 for a black-bezel 10.4" NS-series HMI without Ethernet
- Pick NS10-TV01B-V2 when you need built-in Ethernet
- Pick NS10-TV00-V2 for an ivory-bezel no-Ethernet variant
- Pick NS10-TV01-V2 for ivory bezel + Ethernet combination
- Pick NA5-9W001B-V1 or NA5-12W101B-V1 for new designs — NS-series is discontinued as of April 2022
- Pick NB10W-TW01B if you want a 10.1" NB-series panel that is still in active production
Technical Specifications
| Model | NS10-TV00B-V2 |
|---|---|
| Series | NS-series V2 Programmable Terminals (discontinued) |
| Display Type | TFT color LCD |
| Display Size | 10.4 inches diagonal |
| Resolution | 640 × 480 pixels (VGA) |
| Colors | 32,768 (16-bit colour) |
| Backlight | LED, 50,000 hours to half-brightness |
| Touch Panel | Matrix resistive (analog) |
| Effective Display Area | 211 × 158 mm |
| Rated Supply Voltage | 24 VDC |
| Operating Voltage Range | 20.4 to 27.6 VDC |
| Communication Protocols | Host Link (SYSMAC WAY), NT Link, Modbus RTU slave |
| Operating Temperature | 0 to +50 °C |
| Storage Temperature | -20 to +60 °C |
| Dimensions (W × H × D) | 315 × 241 × 48.5 mm |
Resources & Downloads
FAQ for NS10-TV00B-V2
What's the difference between NS10-TV00B-V2 and NS10-TV01B-V2?
The only functional difference is the Ethernet port. NS10-TV00B-V2 (this SKU) has no built-in Ethernet — it has two serial ports (RS-232C × 1, RS-232C/RS-422/RS-485 × 1) plus USB host/slave. NS10-TV01B-V2 has the same serial ports and USB but adds a 10Base-T/100Base-TX Ethernet port for FINS communications, Tag data link routing with NJ/NX controllers, and remote HMI access via CX-Designer over LAN. If your PLC talks to the HMI over Host Link serial only, the TV00 is the cost-optimised pick.
Is the NS10-TV00B-V2 still in production?
No — Omron discontinued the entire NS-series V2 lineup in April 2022. New units are no longer manufactured. NS10-TV00B-V2 units are still available from distributors' secondary channel stock and remain fully supported for CX-Designer programming, repairs, and spare-part replacement until the channel stock is exhausted. For new designs, the recommended replacement is the NA5-9W001B-V1 (9-inch) or NA5-12W101B-V1 (12.1-inch) Sysmac-family panel, or the NB10W-TW01B if you want a 10.1-inch NB-series panel that is still actively produced.
What software do I use to program the NS10-TV00B-V2?
CX-Designer, which is part of Omron's CX-One automation suite (CX-One v4.0 or later). CX-Designer is the screen-design tool — you build pages with buttons, lamps, numeric entry, trend displays, and graphs, and you bind each element to a bit or word address in the host PLC. You can install CX-One alongside Sysmac Studio on the same PC, but only CX-One is needed for NS-series HMI work.
Can I connect the NS10-TV00B-V2 to a CJ2M-CPU33 over serial?
Yes — the NS10-TV00B-V2 supports Host Link (SYSMAC WAY) and NT Link serial protocols for communication with CJ-series, CP-series, CS-series, and NJ-series PLCs. For a CJ2M-CPU33, use the CJ2M's serial port (RS-232C on the option-board slot) or add a CJ1W-SCU21-V1 / CJ1W-SCU31-V1 serial communication unit to get an RS-232C or RS-422/485 port. Connect the CJ2M serial port to the NS10's port A or port B with a straight-through RS-232C cable (or cross-over depending on the protocol mode).
