Omron NS5-SQ10-V2 — front face of the 5.7-inch NS-series HMI showing the STN colour LCD displaying an operator screen, the ivory bezel, the front-facing function-key strip, the Omron logo and the NS5-SQ10-V2 type label

Omron NS5-SQ10-V2 — 5.7-inch NS5 HMI, RS-232C

SKU: NS5-SQ10-V2

USD 432.00

Omron NS5-SQ10-V2 5.7-inch NS5 HMI, STN colour LCD, RS-232C, 60 MB. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NS5-SQ10-V2 is a 5.7-inch programmable terminal from the NS-series HMI family, manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the CX-Designer project file on a USB drive included.

The display is a 5.7-inch STN colour LCD at QVGA 320 x 240, 256 colours, with a matrix resistive touch panel rated for 1,000,000 touch operations. Screen data memory is 60 MB. Backlight is a user-replaceable LED with 75,000 hours minimum service life and automatic error detection. Power supply is 24 VDC, 15 W max.

Two RS-232C ports (D-sub 9-pin) handle PLC-to-HMI communication; there is no built-in Ethernet on this model. A USB 1.1 slave port (Type-B) and a CompactFlash slot handle project transfer and data logging. Front panel is IP65 / NEMA 4 / UL Type 4 rated. The NS5-SQ10-V2 is discontinued; for an Ethernet-equipped modern replacement, pick the NS5-TQ10-V2. Programming is in CX-Designer, part of CX-One.

Key Features

  • NS-series 5.7-inch STN colour LCD, QVGA 320 x 240, 256 colours, matrix resistive touch (1,000,000 operations)
  • 60 MB screen data memory, CompactFlash slot for project / log / recipe storage, 24 VDC supply at 15 W
  • 2 x RS-232C ports (D-sub 9-pin), USB 1.1 slave (Type-B), no built-in Ethernet
  • Replaceable LED backlight, 75,000 hours minimum, auto error detection, IP65 front face
  • SKU: NS5-SQ10-V2
  • Series: Omron NS-series NS5-V2 programmable terminal (PT)
  • Voltage: 24 VDC

Best-Fit Applications

  • Replacement HMI on an existing serial-only CP1L panel where RS-232C connects to the PLC and no Ethernet migration is in scope
  • Packaging machine operator station where the 5.7-inch screen shows cycle counts, alarms, and operator buttons in 256 colours
  • Spare stock for a facility running older NS5 panels that need a like-for-like replacement without re-engineering the panel cutout

Buying Checklist

  • Pick the NS5-SQ10-V2 for a 5.7-inch NS-series HMI with RS-232C and 60 MB memory on a tight budget.
  • Pick the NS5-SQ10B-V2 instead when the panel needs a black bezel to match a dark-grey enclosure.
  • Pick the NS5-TQ10-V2 instead when the HMI needs built-in Ethernet and the application is a new install (NS5-SQ10-V2 is discontinued).

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NS-series NS5-V2 programmable terminal (PT)
Model / SKU NS5-SQ10-V2
Display 5.7-inch STN colour LCD, QVGA 320 x 240, 256 colours, effective area 115.2 x 86.4 mm
Touch Panel Matrix resistive, 300 switches (20 x 15), 1,000,000 operations
Screen Memory 60 MB screen data
Communication 2 x RS-232C (D-sub 9-pin), USB 1.1 slave (Type-B), CompactFlash slot, no built-in Ethernet
Backlight User-replaceable LED, 75,000 hours min, auto error detection (RUN indicator flashes)
Power Supply 24 VDC (20.4 to 27.6 VDC), 15 W max
Programming CX-Designer (part of CX-One), 42 languages
Protection IP65 front face, NEMA 4 / UL Type 4, ivory bezel
Dimensions / Weight 195 (W) x 142 (H) x 53.8 (D) mm, 1.0 kg max, 0 to 50 C operating

FAQ for NS5-SQ10-V2

Does the NS5-SQ10-V2 have Ethernet?
No. This model has 2 RS-232C ports only. For built-in Ethernet on the same 5.7-inch body, pick the NS5-TQ10-V2 (Ethernet, ivory) or NS5-TQ10B-V2 (Ethernet, black bezel).
Is the NS5-SQ10-V2 still in production?
No. The NS5-SQ10-V2 is discontinued by Omron. The direct modern replacement with Ethernet is the NS5-TQ10-V2. Hengyixin Automation continues to ship new-old-stock and factory-sealed surplus units while supplies last.
What software programs the NS5-SQ10-V2?
CX-Designer, part of the CX-One suite. Projects transfer over USB or CompactFlash. The same CX-Designer projects load on the modern NS5-TQ siblings with no conversion.
What is the screen memory of the NS5-SQ10-V2?
60 MB for screen data, including BMP and JPG images up to 32,768 colours. CompactFlash extends storage for data logging, alarm history, and recipe data.
Can NS5-SQ10-V2 connect to a non-Omron PLC?
Yes. CX-Designer supports several non-Omron PLC protocols over RS-232C, including Mitsubishi and Allen-Bradley drivers. For multi-vendor lines, RS-232C is the only practical option on this specific model.
