Omron NS5-TQ10B-V2 — 5.7" NS HMI, TFT, Serial + USB

SKU: NS5-TQ10B-V2

USD 445.00

NS-series 5.7-inch QVGA TFT color touch HMI, 60 MB memory, RS-232C + RS-422A/485 + USB-B slave, black bezel, 24 VDC.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NS5-TQ10B-V2 is the NS-series 5.7-inch QVGA TFT color touch HMI with two serial ports and a USB-B slave -- no Ethernet and no USB host. The TFT LCD shows 65,536 colors at 320 x 240, a clear step up from the STN-color NS5-SQ10B-V2 and the STN-monochrome NS5-MQ10B-V2 in the same 5.7-inch class. The unit fits the same 184 x 132 mm panel cutout as the older NS5 / NSJ5 5.7-inch series and is the standard pick for a like-for-like replacement.

The TQ vs SQ vs MQ split

The NS5 family uses three display codes at the same 5.7-inch QVGA cutout. TQ = TFT color, 65,536 colors, the typical pick for a vivid operator panel. SQ = STN color, ~4,096 colors, the lower-cost pick for a panel where full color is not required. MQ = STN monochrome (4-shade, blue / yellow mode), the pick for a plain text-and-button panel. All three share the same 184 x 132 mm cutout and the same COM1 / COM2 / USB port set, so the panel builder can pick the display class without re-cutting the cabinet door.

Ethernet and USB host

The TQ10B-V2 has NO Ethernet and NO USB-A host -- only COM1 RS-232C, COM2 RS-422A / RS-485 and the USB-B slave. For 10/100 base-T Ethernet on top of the same ports, pick the NS5-TQ10B-ECV2 (the -ECV2 suffix adds Ethernet). For USB-A host on top of the same ports, the NS5 family does not support a USB memory stick on any model -- pick the NB5Q-TW01B-V1 (5.6-inch) or NB7W-TW01B-V1 (7.0-inch) when a USB-stick recipe transfer is needed.

Before ordering

Confirm the panel cutout is 184 x 132 mm. Confirm CX-Designer 3.0 or later is the programming environment -- the NS5-V1 (predecessor) projects move to the NS5-V2 without rework, but the NS5-V2 project file is not backward compatible to the NS5 V1 (the V1 firmware cannot read a V2 project file). Pick the ECV2 suffix when Ethernet is needed. For a 7-inch or 10-inch upgrade, pick the NS8-TV01B-V2 or NS12-TS01B-V2 from the same V2 generation.

Key Features

  • NS-series 5.7-inch QVGA TFT color touch HMI, 320 x 240 pixels, 65,536 colors
  • White LED backlight, 50,000-hour half-life (no CCFL to replace)
  • 60 MB internal project memory for screens, recipes, alarms, and data logs
  • COM1 RS-232C (D-Sub 9-pin) for Host Link / NT Link / serial protocol macro to a CJ / CP1 / NJ PLC
  • COM2 RS-422A / RS-485 (D-Sub 9-pin) for 1:N NT Link to multiple PLCs at up to 500 m
  • USB-B slave (for CX-Designer 3.0+ project upload / download)
  • No Ethernet (the -ECV2 suffix adds 10/100 base-T), no USB-A host
  • Analog resistive touch, 1,000,000 cycle life
  • 24 VDC (-15 / +15%) supply at 15 W max
  • IP65 front panel only (NOT IP65F or IP67), black bezel (the -B suffix)
  • 190 W x 110 H x 53.5 D mm body at ~1.0 kg
  • Panel cutout 184 x 132 mm (same as NS5-SQ10B-V1 / NS5-MQ10B-V1 / NS5-SQ10-V2)
  • CX-Designer drag-and-drop programming with Smart Active Parts (SAP) library for Omron PLCs
  • 0 to +50 C operating, UL 508 / CE / RCM / KC, MADE IN JAPAN
  • SKU: NS5-TQ10B-V2
  • Series: NS-series Programmable Terminal (touch HMI) V2

Best-Fit Applications

  • Operator panel on a single-machine build where an Ethernet link is not needed and the panel mounts close to the CJ / CP1 PLC
  • Like-for-like replacement on an existing NS5-V1 cutout where the panel builder wants a TFT color upgrade without re-cutting the door
  • 1:N NT Link RS-422A HMI chain across four or five stations on a packaging line
  • Recipe / alarm / status panel on a small-format machine where full-color icons are not required
  • Pickup for an NS5-V2 / NS8-V2 retrofit where the existing CX-Designer project (V2 generation) loads without rework

Buying Checklist

  • Pick NS5-TQ10B-V2 for a 5.7-inch QVGA TFT color touch HMI with RS-232C + RS-422A/485 + USB-B slave, no Ethernet, 60 MB memory.
  • Pick NS5-TQ10B-ECV2 instead when 10/100 base-T Ethernet is needed on top of the same display class.
  • Pick NS5-SQ10B-V2 instead for a STN color display (~4,096 colors) at the same 5.7-inch cutout for a cost-optimized panel.
  • Pick NS5-MQ10B-V2 instead for a STN monochrome display at the same cutout for a plain text-and-button build.
  • Pick NB5Q-TW01B-V1 instead when 5.6-inch QVGA Ethernet + USB-stick recipe transfer is needed on the NB-generation platform.
  • Pair with the XW2Z-100S-V / XW2Z-200S-V USB serial cable for non-USB PLCs (legacy CJ1 RS-232C port).

Technical Specifications

Series NS-series Programmable Terminal (touch HMI) V2
Model NS5-TQ10B-V2 (5.7-inch QVGA TFT color, serial + USB, black bezel)
Display 5.7-inch TFT color LCD, 320 x 240 (QVGA), 65,536 colors, white LED backlight
Display Area 117 x 63 mm
Memory 60 MB internal project memory
Ports COM1 RS-232C + COM2 RS-422A / RS-485 + USB-B slave (NO Ethernet, NO USB host)
Programming CX-Designer 3.0+ drag-and-drop, Smart Active Parts library
Touch Analog resistive, 1,000,000 cycle life
Power 24 VDC -15/+15% at 15 W max
Body Dimensions 190 W x 110 H x 53.5 D mm, ~1.0 kg
Panel Cutout 184 x 132 mm, 1.6 to 5 mm panel thickness
Front Seal / Bezel / Approvals IP65 front panel only / black bezel / UL 508 / CE / RCM / KC, 0 to +50 C

FAQ for NS5-TQ10B-V2

What is the difference between NS5-TQ10B-V2 and NS5-TQ10B-ECV2?
Both are 5.7-inch QVGA TFT color touch HMIs at the same 184 x 132 mm cutout. The TQ10B-V2 is the base model with COM1 RS-232C + COM2 RS-422A / RS-485 + USB-B slave -- NO Ethernet. The TQ10B-ECV2 adds 10/100 base-T Ethernet on top of the same two serial ports. Pick the ECV2 when the HMI needs an Ethernet link to a CJ / NJ / NX PLC. Pick the plain -V2 when the link is serial (Host Link on COM1 or NT Link 1:N on COM2) -- the plain -V2 is the lower-cost pick.
What is the difference between NS5-TQ10B-V2, NS5-SQ10B-V2, and NS5-MQ10B-V2?
All three share the same 5.7-inch QVGA 320 x 240 cutout and the same COM1 + COM2 + USB port set, but differ in display class. TQ = TFT color (65,536 colors, the vivid pick). SQ = STN color (~4,096 colors, the cost-optimized color pick). MQ = STN monochrome (4-shade, blue / yellow mode, the plain text-and-button pick). Pick the TQ for a vivid operator panel; pick the SQ for cost optimization with acceptable color; pick the MQ for a monochrome build. All three run on 24 VDC.
What programming software does the NS5-TQ10B-V2 use?
CX-Designer 3.0 or later, which ships as part of the CX-One FA Integration Tool. CX-Designer is drag-and-drop with a Smart Active Parts (SAP) library of pre-built page elements for Omron PLCs (error logs, ladder monitoring, alarm summaries, trend graphs). An NS5-V1 project can be opened and resaved as a V2 project, but the V2 project file is not backward-compatible to a V1 panel -- the V1 firmware cannot read a V2 project file. The V2 is the currently-active catalog entry.
Can the NS5-TQ10B-V2 swap an older NS5-V1 unit without reworking the cutout?
Yes. The NS5-V1 and NS5-V2 share the same 184 x 132 mm panel cutout and the same mounting screws, so a V1 panel can be unbolted and a V2 panel bolted in. The project file may need to be migrated from V1 to V2 (CX-Designer opens a V1 project and resaves as V2, then uploads). The front panel seal (IP65), supply (24 VDC), and the COM1 / COM2 pinout are unchanged between V1 and V2, so the swap is mechanical only.
