Omron NS5-TQ10-V2 — 5.7-Inch TFT Color HMI
SKU: NS5-TQ10-V2USD 450.00
Omron NS5-TQ10-V2 5.7-inch QVGA TFT color HMI, 320x240, 2 RS-232C + USB, 60 MB, CX-Designer. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NS5-TQ10-V2 is a 5.7-inch colour TFT programmable terminal from the NS5-V2 family, manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the Sysmac Studio or NB-Designer project file on a USB drive included.
The QVGA 320 x 240 screen shows 256 colours (32,768 on BMP / JPG bitmaps). The high-luminance TFT has an LED backlight rated 75,000 hours. Touch is a resistive matrix panel. Project memory is 60 MB and a CompactFlash slot holds recipes and project backups.
The unit runs on 24 VDC 20.4 to 27.6 V at 15 W. Two RS-232C ports (Port A and Port B) and a USB 1.1 slave port handle communication. Front face is IP65. Programming runs in CX-Designer under the CX-One suite. The 195 x 142 x 54 mm body weighs about 1 kg. For a 5.7-inch STN colour version with Ethernet, pick the NS5-TQ11-V2. For an STN colour 5.7-inch panel on the same V2 family, use the NS5-SQ10B-V2.
Key Features
- NS5-V2 5.7-inch high-luminance TFT colour HMI, 320 x 240 QVGA, 256 colours
- 2 x RS-232C ports (Port A / Port B), 1 x USB 1.1 slave, CompactFlash slot
- 24 VDC 15 W supply, 60 MB project memory, IP65 front face
- CX-Designer programming under CX-One, 75,000 hour LED backlight
- SKU: NS5-TQ10-V2
- Series: Omron NS-series programmable terminal (NS5-V2)
- Voltage: 24 VDC
Best-Fit Applications
- Operator panel on a CNC lathe where the colour QVGA shows the spindle RPM, feed rate and alarm log without a separate indicator panel
- Spare replacement on an NS5-V2 cabinet where the CompactFlash recipe card carries the old project and the cutout matches the new unit
- Packaging line status page where the IP65 front face handles daily washdown and the RS-232C port talks to a CP1L PLC on Host Link
Buying Checklist
- Pick the NS5-TQ10-V2 for a 5.7-inch colour TFT HMI with 2 RS-232C ports, 60 MB memory and no Ethernet on the NS5-V2 platform.
- Pick the NS5-TQ11-V2 instead when the HMI needs an Ethernet port on the same 5.7-inch TFT body.
- Pick the NS5-SQ10B-V2 instead when the application fits a 5.7-inch STN colour panel on the same V2 family.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron NS-series programmable terminal (NS5-V2) |
| Model / SKU | NS5-TQ10-V2 |
| Display | 5.7-inch high-luminance TFT colour LCD, 320 x 240 QVGA |
| Colours | 256 colours (32,768 for BMP / JPG bitmaps) |
| Backlight | LED, 75,000 hours rated life |
| Touch Panel | Matrix resistive membrane, 1 million operations |
| Supply Voltage | 24 VDC (20.4 to 27.6 VDC), 15 W max |
| Communication Ports | 2 x RS-232C (D-Sub 9 Port A and Port B), 1 x USB 1.1 slave, CompactFlash slot |
| Project Memory | 60 MB |
| Programming Software | CX-Designer under CX-One |
| Dimensions / Weight | 195 (W) x 142 (H) x 54 (D) mm; ~1 kg |
FAQ for NS5-TQ10-V2
What software programs the NS5-TQ10-V2?
CX-Designer under the CX-One suite. The project supports Smart Active Parts for direct tag binding to Omron CP, CJ and CS-series PLCs over Host Link (RS-232C) or NT Link (1:1 / 1:N).
Does the NS5-TQ10-V2 have Ethernet?
No. The -10 model has no Ethernet port. For an NS5-V2 with Ethernet (EtherNet/IP or FINS), use the NS5-TQ11-V2.
Can I replace an NS5-TQ10-V1 with the -V2 model?
Yes. The -V2 is a drop-in replacement for the -V1 on the same 195 x 142 mm cutout. CX-Designer projects convert in one step. The new -V2 has a longer-life LED backlight.
Is the NS5-TQ10-V2 still in production?
Discontinued for new builds in 2020. Stock is limited at Omron and at distributors. For new designs, use the NB5Q or NB7W HMI family.
