Omron NS5-SQ11B — 5.7-Inch STN Color HMI, Ethernet

SKU: NS5-SQ11B

USD 435.00

Omron NS5-SQ11B 5.7-inch STN color HMI, 320x240, 2 RS-232C + Ethernet + USB, 60 MB, black case. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NS5-SQ11B is a 5.7-inch STN colour touch screen HMI from the NS5-V2 family, manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the Sysmac Studio or NB-Designer project file on a USB drive included.

The QVGA 320 x 240 STN colour screen shows 256 colours (32,768 on BMP / JPG bitmaps). The resistive matrix touch panel takes 1 million operations. Project memory is 60 MB and a CompactFlash slot holds recipes and project backups.

Communication is 2 x RS-232C serial ports, one Ethernet 10 / 100 Base-T port and a USB 1.1 slave port for project upload / download. Supply is 24 VDC 20.4 to 27.6 V at 15 W. Front face is IP65. The case is black (B suffix). 195 x 142 x 54 mm, about 1 kg. Programming runs in CX-Designer under CX-One. For a TFT colour version on the same V2 body, pick the NS5-TQ11-V2. For a modern replacement on a new build, use the NB5Q-TW01B-V1.

Key Features

  • NS5-V2 5.7-inch STN color touch HMI, 320 x 240 QVGA, 256 colors
  • 2 x RS-232C, Ethernet 10/100 Base-T, USB 1.1 slave, CompactFlash slot
  • 24 VDC 15 W supply, 60 MB project memory, IP65 front, black case
  • CX-Designer programming under CX-One, 75,000 hour LED backlight
  • SKU: NS5-SQ11B
  • Series: Omron NS-series programmable terminal (NS5-V2)
  • Voltage: 24 VDC

Best-Fit Applications

  • Operator panel on a CNC lathe where Ethernet pulls job files from the plant server and the QVGA shows spindle RPM
  • Spare replacement on an NS5-V2 cabinet where the CompactFlash recipe card carries the old project and the cutout matches
  • Packaging line status page where the IP65 front handles daily washdown and Ethernet talks to a CJ2 PLC over FINS

Buying Checklist

  • Pick the NS5-SQ11B for a 5.7-inch STN color HMI with Ethernet, 2 RS-232C ports and 60 MB memory on the NS5-V2 family.
  • Pick the NS5-TQ11-V2 instead when the application needs the high-luminance TFT color screen on the same V2 body.
  • Pick the NB5Q-TW01B-V1 instead when the project is a new build and the NB5Q / NB7W family replaces the mature NS series.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NS-series programmable terminal (NS5-V2)
Model / SKU NS5-SQ11B
Display 5.7-inch STN color LCD, 320 x 240 QVGA
Colours 256 colours (32,768 for BMP / JPG bitmaps)
Backlight LED, 75,000 hours rated life
Touch Panel Matrix resistive membrane, 1 million operations
Supply Voltage 24 VDC (20.4 to 27.6 VDC), 15 W max
Communication Ports 2 x RS-232C, 1 x Ethernet 10/100 Base-T, 1 x USB 1.1 slave, CompactFlash slot
Project Memory 60 MB
Programming Software CX-Designer under CX-One
Dimensions / Weight 195 (W) x 142 (H) x 54 (D) mm; about 1 kg

FAQ for NS5-SQ11B

What software programs the NS5-SQ11B?
CX-Designer under the CX-One suite. The project supports Smart Active Parts for direct tag binding to Omron CP, CJ and CS-series PLCs over Host Link, NT Link, or Ethernet FINS.
Does the NS5-SQ11B have Ethernet?
Yes. The 11 suffix marks the Ethernet version on the NS5-V2 family. The 10 suffix (NS5-SQ10B-V2) is serial-only.
Is the NS5-SQ11B still in production?
Discontinued for new builds in 2020. Stock is limited at Omron and at distributors. For new designs, use the NB5Q or NB7W HMI family.
What PLCs can the NS5-SQ11B talk to?
All Omron CP, CJ and CS-series PLCs over Host Link (RS-232C), NT Link 1:1 / 1:N, or Ethernet FINS. Third-party PLCs are supported through Omron protocol converters or generic serial drivers.
Can I migrate an NS5-SQ11B project to an NB HMI?
CX-Designer can export the project, then NB-Designer imports the screens. Some screen resizing and protocol map changes are needed because the NB family uses NB-Designer, not CX-Designer.
