Omron NS5-TQ00-V2 — front face of the 5.7-inch NS-series HMI showing the TFT color LCD displaying an operator screen at QVGA 320 x 240, the ivory bezel around the active area, the Omron logo and the NS5-TQ00-V2 type label on the lower-right

Omron NS5-TQ00-V2 — 5.7-inch NS5 HMI, TFT, RS-232C

SKU: NS5-TQ00-V2

USD 405.00

Omron NS5-TQ00-V2 5.7-inch NS5 HMI, TFT color, 320 x 240, 2 RS-232C, 20 MB. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NS5-TQ00-V2 is a 5.7-inch programmable terminal from the NS-series HMI family, manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the CX-Designer project file on a USB drive included.

The display is a 5.7-inch TFT color LCD at QVGA 320 x 240, showing 32 768 colors with an analog resistive matrix touch panel rated for 1,000,000 operations over a 20 x 16 touch matrix. Screen data memory is 20 MB. The LED backlight has automatic error detection.

Two RS-232C ports (D-sub 9-pin) connect to Omron CP1, CJ, CS, and NJ PLCs; there is no built-in Ethernet on this model. A USB 1.1 slave port (Type-B) handles project upload. The front face is IP65 / NEMA 4 rated. The NS5 series is discontinued; the NA5-7W001S-V1 is the modern Sysmac Studio replacement. For Ethernet, the NS5-TQ10-V2 sibling adds the port. Programming is in CX-Designer.

Key Features

  • NS-series 5.7-inch TFT color LCD, QVGA 320 x 240, 32 768 colors, 20 x 16 matrix touch
  • 20 MB screen data memory, LED backlight with automatic error detection, 1,000,000 touch operations
  • 2 x RS-232C ports (D-sub 9-pin), USB 1.1 slave (Type-B), no built-in Ethernet
  • IP65 / NEMA 4 front face, ivory bezel, 24 VDC supply, 15 W max, discontinued
  • SKU: NS5-TQ00-V2
  • Series: Omron NS-series NS5-V2 programmable terminal (PT)
  • Voltage: 24 VDC

Best-Fit Applications

  • Spare replacement on a packaging line where the existing serial-only CP1L panel keeps a CX-Designer project file with no Ethernet migration in scope
  • Operator station on a small CNC lathe where the 5.7-inch TFT color screen renders cycle-time trends, alarm text, and operator buttons without Ethernet
  • Mid-tier factory panel where the 5.7-inch TFT replaces a 5.7-inch STN NS5-SQ10-V2 for more vivid colour rendering on the same CX-Designer platform

Buying Checklist

  • Pick the NS5-TQ00-V2 for a 5.7-inch NS-series TFT color HMI with RS-232C and 20 MB on a tight budget (discontinued but serviceable).
  • Pick the NS5-TQ10-V2 instead when the HMI needs Ethernet for connection to an NJ / NX PLC over EtherNet/IP.
  • Pick the NS5-TQ00B-V2 instead when the cabinet bezel must be black to match a dark-grey enclosure.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NS-series NS5-V2 programmable terminal (PT)
Model / SKU NS5-TQ00-V2
Display 5.7-inch TFT color LCD, QVGA 320 x 240, 32 768 colors
Effective Display Area 115.2 x 86.4 mm
Touch Panel Analog resistive matrix, 20 x 16 touch matrix, 1,000,000 operations
Screen Memory 20 MB screen data
Communication 2 x RS-232C (D-sub 9-pin), USB 1.1 slave (Type-B), no Ethernet
Backlight LED with auto error detection (RUN indicator flashes when near end of life)
Power Supply 24 VDC (20.4 to 27.6 VDC), 15 W max
Programming CX-Designer (part of CX-One), 42 display languages
Protection / Environment IP65 front face, NEMA 4, ivory bezel, 0 to 50 C, 35 to 85% RH non-condensing, 195 (W) x 142 (H) x 38.2 (D) mm, 1.0 kg

FAQ for NS5-TQ00-V2

Does the NS5-TQ00-V2 have Ethernet?
No. This model has 2 RS-232C ports only. For built-in Ethernet on the same 5.7-inch body, pick the NS5-TQ10-V2 (Ethernet, ivory) or NS5-TQ10B-V2 (Ethernet, black bezel).
Is the NS5-TQ00-V2 still in production?
No. The NS5 series is discontinued by Omron. The recommended modern replacement on Sysmac Studio is the NA5-7W001S-V1 (7-inch widescreen, EtherNet/IP, black bezel). Hengyixin Automation continues to ship new-old-stock and factory-sealed surplus units while supplies last.
What software programs the NS5-TQ00-V2?
CX-Designer, part of the CX-One suite. Projects transfer over USB. CX-Designer projects also load on the modern NA5-series Sysmac Studio platforms with no conversion.
NS5-TQ00-V2 vs NS5-SQ10-V2 - what is the difference?
The NS5-TQ00-V2 is a TFT colour LCD showing 32 768 colors. The NS5-SQ10-V2 is an STN colour LCD showing 4 096 colors. The TFT has better viewing angle and faster response; the STN is lower cost.
