Part of the Omron NS Series Operator Terminals series — see the full model table, lifecycle status and replacement parts.

Omron NS8-TV00-V2 — front face of the 8.4-inch NS-series HMI showing the TFT color LCD displaying an operator screen, the ivory bezel around the active area, the Omron logo and the NS8-TV00-V2 type label on the lower-right

Omron NS8-TV00-V2 — 8.1-inch NS8 HMI, RS-232C

SKU: NS8-TV00-V2

USD 735.00

Omron NS8-TV00-V2 8.1-inch NS8 HMI, TFT colour, 640 x 480, 2 RS-232C, 60 MB. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NS8-TV00-V2 is an 8.1-inch programmable terminal from the NS-series HMI family, manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the CX-Designer project file on a USB drive included.

The display is an 8.1-inch TFT color LCD at VGA 640 x 480, showing 256 colors on screen and 32 768 colors for BMP / JPG image objects. The matrix resistive touch panel is rated for 1,000,000 touch operations over a 20 x 16 matrix. Screen data memory is 60 MB. The LED backlight has automatic error detection.

Two RS-232C ports (D-sub 9-pin) connect to Omron CP1, CJ, CS, and NJ PLCs; there is no built-in Ethernet on this model. A USB 1.1 slave port (Type-B) handles project upload. The front face is IP65 / NEMA 4 rated for use on the cabinet door. The NS8-TV00-V2 is discontinued by Omron; the NA5-9W001S-V1 is the modern Sysmac Studio replacement. For Ethernet, the NS8-TV01-V2 sibling adds the port. Programming is in CX-Designer.

Key Features

  • NS-series 8.1-inch TFT color LCD, VGA 640 x 480, 256 on-screen colors (32 768 for BMP / JPG)
  • Matrix resistive touch, 20 x 16 matrix, 1,000,000 touch operations, 60 MB screen memory
  • 2 x RS-232C ports (D-sub 9-pin), USB 1.1 slave (Type-B), no built-in Ethernet
  • IP65 / NEMA 4 front face, ivory bezel, 24 VDC supply, 25 W max, discontinued
  • SKU: NS8-TV00-V2
  • Series: Omron NS-series NS8-V2 programmable terminal (PT)
  • Voltage: 24 VDC

Best-Fit Applications

  • Spare replacement on an existing serial-only CP1L panel where the project file is in CX-Designer and no Ethernet migration is in scope
  • Operator station on a packaging machine where 256 colors are enough for cycle count, alarms, and operator buttons on a small 8.1-inch screen
  • Mid-tier factory panel where the 8.1-inch TFT replaces a 5.7-inch STN NS5 for more detailed trend graphs without leaving the NS series

Buying Checklist

  • Pick the NS8-TV00-V2 for an 8.1-inch NS-series HMI with RS-232C and 60 MB on a tight budget (discontinued but serviceable).
  • Pick the NS8-TV01-V2 instead when the HMI needs built-in Ethernet for connection to an NJ/NX PLC over EtherNet/IP.
  • Pick the NS8-TV00B-V2 instead when the cabinet bezel must be black to match a dark-grey enclosure.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NS-series NS8-V2 programmable terminal (PT)
Model / SKU NS8-TV00-V2
Display 8.1-inch TFT color LCD, VGA 640 x 480, 256 on-screen colors (32 768 for BMP / JPG)
Effective Display Area 170.9 x 128.2 mm
Touch Panel Matrix resistive, 20 x 16 matrix, 1,000,000 operations
Screen Memory 60 MB screen data
Communication 2 x RS-232C (D-sub 9-pin), USB 1.1 slave (Type-B), no Ethernet
Backlight LED with auto error detection (RUN indicator flashes when near end of life)
Power Supply 24 VDC (20.4 to 27.6 VDC), 25 W max
Programming CX-Designer (part of CX-One), 42 languages
Protection / Environment IP65 front face, NEMA 4, ivory bezel, 0 to 50 C, 35 to 85% RH non-condensing, 232 (W) x 177 (H) x 54.8 (D) mm, 2.0 kg

FAQ for NS8-TV00-V2

Does the NS8-TV00-V2 have Ethernet?
No. This model has 2 RS-232C ports only. For built-in Ethernet on the same 8.1-inch body, pick the NS8-TV01-V2 (Ethernet, ivory) or NS8-TV01B-V2 (Ethernet, black bezel).
Is the NS8-TV00-V2 still in production?
No. The NS8-TV00-V2 is discontinued by Omron. The recommended modern replacement on Sysmac Studio is the NA5-9W001S-V1 (9-inch widescreen, EtherNet/IP, black bezel). Hengyixin Automation continues to ship new-old-stock and factory-sealed surplus units while supplies last.
What software programs the NS8-TV00-V2?
CX-Designer, part of the CX-One suite. Projects transfer over USB. CX-Designer projects also load on the modern NA5-series Sysmac Studio platforms with no conversion.
Can NS8-TV00-V2 connect to a non-Omron PLC?
Yes. CX-Designer supports several non-Omron PLC protocols over RS-232C, including Mitsubishi and Allen-Bradley drivers. For multi-vendor lines RS-232C is the only practical option on this specific model.
What is the screen resolution of the NS8-TV00-V2?
640 x 480 VGA on an 8.1-inch TFT color LCD. 256 colors are usable on screen, with 32 768 available for imported BMP and JPG image objects.
