Omron NX-CSG320 — NX Safety Communication
SKU: NX-CSG320USD 1050.00
Omron NX-CSG320 NX-series Communication Control Unit for CIP Safety over EtherNet/IP, SIL 3, 3 ports, 72 x 100 x 90 mm, 390 g. China stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX-CSG320 is the Communication Control Unit for an NX-series safety stack. It is manufactured by Omron Corporation. Hengyixin Automation stocks this safety device in Xiamen and ships within 3-5 business days.
Omron's published data for this model: it is a Communication type module on the NX I/O Bus, rated Suitable for safety functions: TRUE with SIL 3 per IEC 61508. It carries 3 communication ports on EtherNet/IP. The enclosure is IP20 and measures 72 (W) x 100 (H) x 90 (D) mm, 390 g.
It is the EtherNet/IP head with CIP Safety routing and the NX I/O bus master. It is not a safety controller: an NX-SL5@@@ safety CPU Unit is required to run the safety logic, host the safety program and source the CIP-Safety connections. Compatible controllers and sibling SKUs are listed in the related products row below.
Omron's catalogue lists these spare parts for the NX-CSG320: the NX-TBC082 screwless push-in connector with 8 wiring terminals (marked A+B+FG), NX-AUX02 terminal block coding pins (pack of 10 units), and Cat.6A Ethernet patch cables from 20 cm to 20 m.
Key Features
- NX-series Communication Control Unit for a safety stack, on the NX I/O Bus
- Omron catalogue: Suitable for safety functions TRUE, SIL 3 per IEC 61508
- 3 communication ports on EtherNet/IP
- 72 (W) x 100 (H) x 90 (D) mm, 390 g, IP20
- Spare connector NX-TBC082, 8 screwless push-in terminals (A+B+FG); not included
- Requires an NX-SL5@@@ safety CPU Unit to run the safety logic -- the CSG320 is the communication head, not the safety controller
- SKU: NX-CSG320
- Series: Omron NX-series Communication Control Unit (NX-CSG)
Best-Fit Applications
- NX-SL5@@@ safety CPU uplink for an NJ / NX non-safety machine controller sharing the same EtherNet/IP network
- Spare unit on an existing safety stack where a CSG320 fault needs a like-for-like replacement (Ver. 1.01 firmware)
- Head of a CIP Safety on EtherNet/IP safety stack driving safety I/O on a packaging machine
Buying Checklist
- Pick the NX-CSG320 when the safety CPU is an NX-SL5@@@ and the network is CIP Safety on EtherNet/IP.
- Pick the NX-SL5700 as the matching safety CPU for a 2032-point / 254-connection build (the higher-density safety CPU).
- Pick the NX-SOD400 / NX-SOH200 for the safety output units that sit behind the CSG on the local NX backplane.
Technical Specifications
| Series | Omron NX-series Communication Control Unit (NX-CSG) |
|---|---|
| Model | NX-CSG320 |
| Type of Module | Communication |
| I/O System | NX I/O Bus |
| Safety Integrity | Suitable for safety functions: TRUE; SIL 3 per IEC 61508 |
| Communication Ports | 3, EtherNet/IP |
| Connection | NX-TBC082 screwless push-in connector with 8 wiring terminals (marked A+B+FG); NX-AUX02 terminal block coding pins |
| Dimensions / Weight | 72 (W) x 100 (H) x 90 (D) mm, 390 g |
| Protection | IP20 |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NX-CSG320
What is the difference between NX-CSG320 and NX-SL5500?
Role. The NX-CSG320 is the COMMUNICATION CONTROL UNIT -- the EtherNet/IP head with CIP Safety routing and the NX I/O bus master. The NX-SL5500 is the SAFETY CPU UNIT, which runs the safety logic and hosts the safety program. A safety stack needs both.
Can the NX-CSG320 work without an NX-SL safety CPU?
No. The CSG320 is a COMMUNICATION CONTROL UNIT, not a safety controller. An NX-SL5@@@ safety CPU is required to run the safety logic, host the safety program and source the CIP-Safety connections.
What is the SIL rating of the NX-CSG320?
SIL 3 per IEC 61508. Omron's catalogue records Suitable for safety functions: TRUE and SIL according to IEC 61508: 3 for this model.
What connector does the NX-CSG320 use?
Omron lists NX-TBC082 as the replacement spare -- a screwless push-in connector with 8 wiring terminals, marked A+B+FG. NX-AUX02 terminal block coding pins (10 units) are listed alongside it. The connector is not included with the unit.
