Omron NX-ID3417 — front face of the 12 mm-wide NX I/O unit showing the green TS indicator LED at the upper left, the four yellow input status LEDs, the NX-ID3417 model label and the screwless terminal block at the bottom

Omron NX-ID3417 — NX 4-Point PNP DC Input Unit

SKU: NX-ID3417

USD 52.50

Omron NX-ID3417 NX-series 4-point DC input unit, PNP, 12-24 VDC, 20 us response, 12 mm wide. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NX-ID3417 is a 4-point DC input unit from the NX-series I/O platform, manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

The unit ships with four PNP digital inputs on a screwless clamping terminal block with 12 terminals. Rated input voltage is 12 to 24 VDC, operating 9 to 28.8 VDC. Input current is 6 mA typical at 24 VDC. ON is 9 VDC min / 3 mA min and OFF is 2 VDC max / 1 mA max.

ON/OFF response time is 20 us / 400 us. Filter: no, 0.25, 0.5, 1 (default), 2, 4, 8, 16, 32, 64, 128, 256 ms. Refresh mode - synchronous I/O or Free-Run - is set in Sysmac Studio. Photocoupler isolation, 0.90 W from NX bus, 12 x 100 x 71 mm, 65 g. For 8 PNP inputs in the same 12 mm body, pick the NX-ID5342; for an NPN-input version, the NX-ID4442.

Key Features

  • NX-series 4-point PNP DC input unit, screwless clamping terminal block (12 terminals, detachable)
  • Rated input 12-24 VDC (9-28.8 VDC operating), 6 mA typical at 24 VDC, ON 9 VDC / 3 mA, OFF 2 VDC / 1 mA
  • 20 us ON / 400 us OFF response, selectable filter 0.25 to 256 ms, synchronous or Free-Run I/O refreshing
  • Photocoupler isolation, 0.90 W max from NX bus, 12 (W) x 100 (H) x 71 (D) mm, 65 g, IP20
  • SKU: NX-ID3417
  • Series: Omron NX-series digital I/O unit
  • Voltage: 12 TO 24 VDC
  • I/O: 4 I/O

Best-Fit Applications

  • Fast sensor hub on a filling machine where four PNP prox-sensors on a single 12 mm NX block share one EtherCAT node
  • Cylinder-end-position feedback on a packaging line where the 20 us ON response catches the magnet position before the next index
  • Spare module on an existing NX-series rack where the slot count is fixed and a like-for-like 4-point PNP replacement is required

Buying Checklist

  • Pick the NX-ID3417 for an NX-series 4-point PNP DC input unit with a 20 us ON response.
  • Pick the NX-ID3443 instead when the panel needs 100 ns ON/OFF for high-speed synchronization with the controller scan.
  • Pick the NX-ID5342 instead when the panel needs 8 PNP inputs rather than 4, in a wider 12 mm module.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NX-series digital I/O unit
Model / SKU NX-ID3417
Number of Points 4 digital inputs (PNP / sourcing)
Rated Input Voltage 12 to 24 VDC (9 to 28.8 VDC operating)
Input Current 6 mA typical at 24 VDC
ON / OFF Threshold ON 9 VDC min / 3 mA min; OFF 2 VDC max / 1 mA max
ON / OFF Response 20 us max ON / 400 us max OFF
Input Filter No filter, 0.25, 0.5, 1 (default), 2, 4, 8, 16, 32, 64, 128, 256 ms
I/O Refresh Synchronous I/O refreshing or Free-Run refreshing (selectable)
Connection Screwless clamping terminal block, 12 terminals, detachable (NX-TBA122 spare)
Isolation / Environment Photocoupler isolation, 510 VAC dielectric, 20 Mohm at 100 VDC, IP20, 0 to +55 C

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NX-ID3417

What is the input type of the NX-ID3417?
PNP (sourcing) input. The unit expects a contact or sensor that pulls the input line to +24 VDC to register ON. For NPN (sinking) field devices, pick the NX-ID4442 or NX-ID5442 sibling.
How fast is the NX-ID3417?
ON response is 20 us max and OFF response is 400 us max. For 100 ns ON/OFF - typical for registration-mark or cam-based synchronous control - pick the NX-ID3443.
Can the NX-ID3417 take an NPN sensor?
No. The NX-ID3417 is PNP-only; an NPN sensor wired to this unit would not register ON reliably. Use the NX-ID4442 for NPN, or re-wire the field device to PNP.
What software configures the NX-ID3417?
Sysmac Studio (part of CX-One / Sysmac Studio). Set I/O refresh mode (Synchronous or Free-Run), input filter time, and I/O allocation under the EtherCAT / NX configuration editor.
