Omron NX-ID4442 — front face of the 8-point NX digital input unit showing the row of 8 green input-status LEDs at the top, the TS indicator, the lower 16-terminal detachable screwless push-in connector with orange release lever and the NX-ID4442 type label

Omron NX-ID4442 — 8-Point PNP Digital Input, 12 mm

SKU: NX-ID4442

USD 55.50

Omron NX-ID4442 NX digital input, 8 PNP at 24 VDC, 20 us response, 12 mm wide. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NX-ID4442 is a digital input unit from the NX-series I/O family, manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series I/O System brochure (R183).

The unit provides 8 PNP digital inputs at 24 VDC (15 to 28.8 VDC) on a single 16-terminal screwless push-in connector. Input current is 3.5 mA typical per point. ON voltage 15 VDC min, ON current 3 mA min; OFF voltage 5 VDC max, OFF current 1 mA max. Response times are 20 us ON, 400 us OFF.

Refresh method is selectable between synchronous and free-run. Input filter is configurable from no filter to 256 ms in 13 steps, 1 ms factory setting. Photocoupler isolation separates inputs from the NX bus. I/O power is supplied from the NX bus at 0.1 A per IOV terminal. For the NPN sibling, pick the NX-ID4342; for 16 PNP points, the NX-ID5442. Programming is in Sysmac Studio.

Key Features

  • NX-series digital input unit, 8 PNP points at 24 VDC (15 to 28.8 VDC), 3.5 mA per point typical
  • 20 us ON / 400 us OFF response, configurable input filter from no filter to 256 ms (1 ms factory setting)
  • Selectable synchronous I/O or free-run refreshing, photocoupler isolation between input and NX bus
  • Single 16-terminal detachable screwless push-in connector, 12 mm wide, IP20, 65 g
  • SKU: NX-ID4442
  • Series: Omron NX-series digital input unit
  • Voltage: 24 VDC
  • I/O: 8 I/O

Best-Fit Applications

  • Conveyor sensor bank where 8 PNP photoeyes wire into one slim 12 mm module and the 20 us ON response catches small parts
  • Spare replacement on a packaging line where an older wide terminal block has been replaced with the slimmer NX-ID4442 to save DIN-rail space
  • Cell safety I/O where the NX-ID4442 handles non-safety status inputs alongside an NX-SID800 safety input module on the same NX bus

Buying Checklist

  • Pick the NX-ID4442 for an 8-point PNP 24 VDC digital input unit in the slimmest 12 mm NX body.
  • Pick the NX-ID4342 instead when the field sensors are NPN (sinking) rather than PNP (sourcing).
  • Pick the NX-ID5442 instead when the panel needs 16 PNP points in a 24 mm wide housing.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NX-series digital input unit
Model / SKU NX-ID4442
Number of Points 8 digital inputs, PNP internal common
Rated Input Voltage 24 VDC (15 to 28.8 VDC)
Input Current 3.5 mA typical at 24 VDC
ON / OFF Threshold ON 15 VDC min / 3 mA min, OFF 5 VDC max / 1 mA max
ON / OFF Response 20 us max ON, 400 us max OFF
Input Filter No filter, 0.25, 0.5, 1 (factory), 2, 4, 8, 16, 32, 64, 128, 256 ms
I/O Refreshing Selectable synchronous I/O or free-run refreshing
Connection 16-terminal detachable screwless push-in connector, 2-wire
Isolation / Environment Photocoupler isolation, 510 VAC dielectric, 0.90 W max on CPU, 12 (W) x 100 (H) x 71 (D) mm, 65 g

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NX-ID4442

What sensors work with the NX-ID4442?
Any 24 VDC PNP (sourcing) sensor, including photoeyes, proximity sensors, limit switches, and pushbuttons. ON voltage 15 VDC min and ON current 3 mA min are the minimum thresholds. NPN sensors need the NX-ID4342 sibling.
Does the NX-ID4442 support synchronous I/O refreshing?
Yes. The refresh method is selectable between synchronous I/O refreshing (locked to the NX bus cycle) and free-run refreshing (immediate). Use synchronous for high-speed deterministic control and free-run for slower status inputs.
What is the input filter on the NX-ID4442?
13 settings from no filter to 256 ms, with 1 ms as the factory setting. Filter is set per point in Sysmac Studio. Longer filters reject contact bounce but add input latency.
NX-ID4442 vs NX-ID3417 - what is the difference?
NX-ID4442 is 8 PNP points in 12 mm at standard speed. NX-ID3417 is 4 PNP points in 12 mm with high-speed 100 ns response for registration / encoder inputs. Pick the 3417 for fast signals and the 4442 for normal status inputs.
Does the NX-ID4442 need a separate power supply?
No. I/O power is supplied from the NX bus at 0.1 A per IOV terminal. The unit draws 0.90 W max from the CPU or 0.50 W max from a coupler.
