Omron NX-ILM400 — front view of the IO-Link master showing the four-port terminal block across the top, the NX-series latch on the right side, and the Omron model label below

Omron NX-ILM400 — NX IO-Link Master, 4 Ports

SKU: NX-ILM400

USD 125.00

Omron NX-ILM400 NX-series IO-Link master, 4 ports, IO-Link v1.1, COM1/2/3, push-in terminals. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NX-ILM400 is an NX-series IO-Link master unit with four ports, manufactured by Omron Corporation. Hengyixin Automation stocks this controller option board in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

Each of the four ports runs IO-Link v1.1 at COM1 (4.8 kbps), COM2 (38.4 kbps) or COM3 (230.4 kbps). The unit also reads PNP digital inputs and drives PNP digital outputs in SIO mode. Maximum cable run is 20 m per port. Wiring lands on a 16-terminal push-in (screwless clamping) block that releases with a flat-blade screwdriver.

Supply is 24 VDC at 20.4 to 28.8 VDC. Output current is 0.1 A per port. The unit is 12 x 100 x 71 mm, IP20, and mounts on DIN rail next to an NX-ECC201 EtherCAT coupler or NX-EIC202 EtherNet/IP coupler. Configuration runs in Sysmac Studio. Sibling I/O units include the NX-ID5342 and NX-OD4256.

Key Features

  • NX-series IO-Link master with 4 ports and IO-Link v1.1 conformance
  • COM1 / COM2 / COM3 (4.8 kbps, 38.4 kbps, 230.4 kbps), 20 m max cable
  • 16-terminal push-in (screwless clamping) I/O block, IP20, DIN rail mount
  • Configured in Sysmac Studio; drops onto NX-ECC201 or NX-EIC202 coupler
  • SKU: NX-ILM400
  • Series: Omron NX-series I/O
  • Voltage: 24 VDC

Best-Fit Applications

  • Wiring a four-station rotary table where each station reads an E2E IO-Link proximity sensor for part-present into the CIO area
  • Picking up IO-Link process data from a FESTO pressure sensor on a packaging-line air regulator and exposing it to the NJ controller over EtherCAT
  • Field-replacement on an existing NX rack where the prior IO-Link block failed and the four-port count is fixed

Buying Checklist

  • Pick the NX-ILM400 for an NX-series IO-Link master with 4 ports and a push-in screwless terminal block.
  • Pick the NX-ILM400 when the rack already runs an NX-ECC201 EtherCAT or NX-EIC202 EtherNet/IP coupler -- it drops onto either.
  • Pick a CompoNet or DRT2 master instead when the existing fieldbus is CompoNet and the cabinet does not use NX-series hardware.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NX-series I/O
Model / SKU NX-ILM400
Module Type IO-Link master, 4 ports
IO-Link Version v1.1.2 (Interface and System Spec; Test Spec)
Baud Rates COM1 4.8 kbps / COM2 38.4 kbps / COM3 230.4 kbps
SIO Mode I/O PNP digital input + PNP digital output
Supply Voltage 24 VDC, 20.4 to 28.8 VDC
Output Current 0.1 A max per port
I/O Connection Push-in screwless clamping terminal block, 16 terminals (A/B)
Max Cable Length 20 m per port
Dimensions / Protection 12 (W) x 100 (H) x 71 (D) mm, 67 g, IP20

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NX-ILM400

What does the Omron NX-ILM400 do?
It adds four IO-Link v1.1 ports to an NX-series control rack. Each port can run an IO-Link sensor or actuator at COM1, COM2 or COM3, or fall back to a standard PNP digital input or output when the device is not IO-Link.
Which NX coupler does the NX-ILM400 work with?
It drops onto either an NX-ECC201 EtherCAT coupler or an NX-EIC202 EtherNet/IP coupler. It also works with the NX-ECC202 and NX-ECC203 variants. The coupler choice is set by the host controller, not the I/O unit.
How is the NX-ILM400 configured?
In Sysmac Studio. Add the unit under the chosen NX coupler, set the port mode (IO-Link, SIO-DI or SIO-DO), and download. The IO-Link device description file (IODD) is loaded automatically once the device is connected.
What is the maximum IO-Link cable length on the NX-ILM400?
20 m per port, per the official NX-ILM400 specification page. That matches the IO-Link v1.1 limit and assumes a 3-wire or 4-wire cable with loop resistance under 6 ohm.
