Omron NX-OD5121-1 — NX Output, 16 NPN, 30 mm

SKU: NX-OD5121-1

USD 62.00

Omron NX-OD5121-1 NX-series 16-point NPN output, 0.5 A/point, M3 screw terminal, 30 mm wide. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NX-OD5121-1 is a 16-point digital transistor output unit, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series I/O System brochure (R183).

The unit ships 16 NPN (sinking) outputs at 0.5 A per point and 5 A per unit. Rated voltage is 12 to 24 VDC and the operating range is 10.2 to 28.8 VDC. ON response is 0.1 ms max, OFF response is 0.8 ms max. I/O refresh is selectable between Free-Run and Synchronous. Each output is isolated from the NX bus by a photocoupler, but Omron's catalogue records Short-circuit protected outputs: FALSE -- there is no load short-circuit protection on this unit.

The terminal block is a removable 18-point M3 screw block. The unit is 30 mm wide, 100 mm tall, and 95 mm deep, weighing 125 g. It drops onto the NX bus after an NX-ECC201 EtherCAT coupler or an NX-EIC202 EtherNet/IP coupler. For the 12 mm push-in sibling, pick the NX-OD5121.

Key Features

  • NX-series 16-point NPN (sinking) transistor output, 0.5 A per point, 5 A per unit
  • 12-24 VDC rated, 10.2-28.8 VDC operating, 0.1 ms ON / 0.8 ms OFF response. Omron's catalogue records Short-circuit protected outputs: FALSE
  • Removable 18-point M3 screw terminal block, 30 mm wide, photocoupler isolation
  • Mounts on the NX bus after an NX-ECC201 EtherCAT or NX-EIC202 EtherNet/IP coupler
  • SKU: NX-OD5121-1
  • Series: Omron NX-series digital I/O unit
  • Voltage: 12 TO 24 VDC

Best-Fit Applications

  • Solenoid-valve bank on a machine where the 16 NPN outputs drive 24 VDC valves directly from the NX bus
  • Spare replacement for an NX-OD5121 on a retrofit where the cabinet was wired for M3 screw terminals
  • Output slice on an NX102 EtherCAT drop where the unit sits next to the NX-ECC201 coupler in a high-vibration cabinet

Buying Checklist

  • Pick the NX-OD5121-1 for a 16-point NPN NX output with a removable M3 screw terminal block.
  • Pick the NX-OD5121 instead when the cabinet uses 12 mm push-in wiring and the smaller body is acceptable.
  • Pick the NX-OD5256-1 instead when the load needs PNP (sourcing) outputs instead of NPN (sinking).

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NX-series digital I/O unit
Model / SKU NX-OD5121-1
Number of Outputs 16 NPN (sinking) transistor outputs
Rated Voltage 12 to 24 VDC
Operating Range 10.2 to 28.8 VDC
Output Current 0.5 A per point, 5 A per unit
ON / OFF Response 0.1 ms max / 0.8 ms max
I/O Refresh Synchronous or Free-Run selectable
Protection Photocoupler isolation. Omron's catalogue records Short-circuit protected outputs: FALSE
Terminal Block 18-point M3 screw, removable
Dimensions / Weight 100 (H) x 30 (W) x 95 (D) mm, 125 g, IP20

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NX-OD5121-1

What is the difference between NX-OD5121 and NX-OD5121-1?
NX-OD5121 is the 12 mm push-in variant. NX-OD5121-1 is the 30 mm M3 screw variant. Both share the same 16-point NPN output, the same 0.5 A per point rating, and the same 5 A total limit.
Does the NX-OD5121-1 need an external power supply?
No fixed supply is needed. Power is drawn from the NX bus through the upstream coupler (NX-ECC201 or NX-EIC202). The 12-24 VDC load voltage is fed to the V+ and V- terminals on the unit.
Can the NX-OD5121-1 fit on an NX1P2 CPU?
Yes. The NX-OD5121-1 connects directly to the right side of an NX1P2 CPU or any NX-series EtherCAT / EtherNet/IP coupler.
Does the NX-OD5121-1 have short-circuit protection?
No. Omron's catalogue records Short-circuit protected outputs: FALSE for the NX-OD5121-1, so a load short circuit is not detected or latched by the unit. For inductive loads, fit a flyback diode or an RC snubber across each coil, and a fuse or protector block if the load can fault to earth.
How is the terminal block removed on the NX-OD5121-1?
Pull straight down on the orange release lever below the terminal block. The block slides off the unit body for bench wiring. Do not pull on the wires.
