Omron NX-OD5121-5 — NX 16-Pt NPN Output, MIL, 30 mm
SKU: NX-OD5121-5USD 72.00
Omron NX-OD5121-5 NX-series 16-point NPN transistor output with MIL connector, 24 VDC, 0.5 A/point. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX-OD5121-5 is the NX-series 16-point NPN transistor output unit with MIL connector, manufactured by Omron Corporation. Hengyixin Automation stocks this controller option board in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series I/O System brochure (R183).
It plugs into the NX I/O bus behind an NX-ECC201 EtherCouCoupler, NX102, or NX1P2 CPU and gives 16 NPN outputs at 0.5 A per point, 2 A per unit. Load voltage 10.2 to 28.8 VDC; rated 24 VDC. ON / OFF response 0.1 ms / 0.8 ms max. Leakage current 0.1 mA max; residual voltage 1.5 V max. Photocoupler isolation to 510 VAC for 1 min.
Connection is a MIL20 plug (not included); use XW2D-20G6, XW2K-20G-T, or XW2Z-xxxxDL-L to land wires. The slice is 30 mm wide, 100 x 71 mm, 80 g. Synchronous or Free-Run refreshing. SIL None. For the PNP sibling at the same MIL connector pick NX-OD5256-5. For a 32-point NPN MIL output pick NX-OD6121-5.
Key Features
- NX-series 16-point NPN (sinking) transistor output unit with MIL20 connector (not included), 30 mm wide body
- 24 VDC rated / 10.2 to 28.8 VDC load voltage range, 0.5 A per point and 2 A per unit, 0.1 ms ON / 0.8 ms OFF response
- Photocoupler isolation to 510 VAC for 1 min, leakage current 0.1 mA max, residual voltage 1.5 V max
- Synchronous or Free-Run refreshing, NX unit power 0.65 W max, 30 x 100 x 71 mm, 80 g, SIL None (not for safety)
- SKU: NX-OD5121-5
- Series: NX-series Digital Output Unit (NX-OD family) on NX I/O Bus and EtherCAT Coupler
- Voltage: 24 VDC
Best-Fit Applications
- Driving 16 solenoid valves on a small machine where the XW2D-20G6 terminal block lands the field wiring to the MIL20 connector
- Replacing a 16-point relay output on a legacy Omron C200H rack with an NX-ECC201 EtherCAT Coupler and an NJ501-1300 Sysmac CPU
- Spare replacement on a labeling machine where the original NX-OD5121-5 was lost and Sysmac Studio tag database points at the same I/O map
Buying Checklist
- Pick the NX-OD5121-5 when the panel needs 16 NPN (sinking) outputs on a 30 mm wide slice with a MIL connector.
- Pick the NX-OD5121-1 instead when the field wires need M3 screw terminals instead of a MIL connector on the same 16-point NPN body.
- Pick the NX-OD5256-5 instead when the loads need PNP (sourcing) instead of NPN (sinking) at the same 16-point MIL connector body.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | NX-series Digital Output Unit (NX-OD family) on NX I/O Bus and EtherCAT Coupler |
| Model / SKU | NX-OD5121-5 |
| Number of Outputs | 16 points, NPN (sinking) transistor, internal I/O common |
| Rated Voltage | 24 VDC; permitted load voltage 10.2 to 28.8 VDC |
| Output Current | 0.5 A per point; 2 A per NX unit |
| ON / OFF Response | 0.1 ms max ON / 0.8 ms max OFF |
| Leakage / Residual | Leakage current 0.1 mA max; residual voltage 1.5 V max |
| Connection | MIL20 connector (not included); mating cable XW2D-20G6 terminal block or XW2Z-xxxxDL-L pre-wired cable |
| Isolation / Power | Photocoupler isolation, 510 VAC 1 min between I/O and internal circuit; NX unit power 0.65 W max |
| Protection | Omron's catalogue records Short-circuit protected outputs: FALSE; no disconnection detection |
| Dimensions / Approvals | 30 (W) x 100 (H) x 71 (D) mm; 80 g; IP20; SIL None (not for safety); CE, cULus, RCM, KC, Lloyd |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NX-OD5121-5
What is the Omron NX-OD5121-5 used for?
It is the NX-series 16-point NPN transistor output unit with a MIL20 connector on a 30 mm wide body. Typical uses are driving 16 solenoid valves on a small machine, replacing a 16-point relay output on a legacy Omron C200H rack with an NX-ECC201 EtherCAT Coupler, and spare replacement on a labeling machine where the Sysmac Studio tag database points at the same I/O map.
NX-OD5121-5 vs NX-OD5121-1 - what is the difference?
Both are NX-series 16-point NPN transistor outputs with 0.5 A per point. The NX-OD5121-5 has a MIL20 connector on a 30 mm wide body. The NX-OD5121-1 has an M3 screw terminal block on a 12 mm wide body. Pick the NX-OD5121-5 when the panel uses pre-wired XW2Z cables or an XW2D terminal block; pick the NX-OD5121-1 when the panel lands wires directly with no extra cabling.
Does the NX-OD5121-5 need a MIL connector?
Yes. The MIL20 connector is not included with the slice. Order an XW2D-20G6 terminal block for direct screw landings, an XW2K-20G-T push-in wiring system, or an XW2Z-xxxxDL-L pre-wired cable (1 m, 2 m, 5 m lengths) for a remote MIL20 to open-end termination. The G70A-ZOC16-3 DC24 output terminal block is a 16-point NPN relay-output adapter that also fits.
What is the maximum switching current on the NX-OD5121-5?
0.5 A per point and 2 A per NX unit, at 24 VDC rated with a permitted load voltage range of 10.2 to 28.8 VDC. ON / OFF response is 0.1 ms ON max / 0.8 ms OFF max, which makes it suitable for high-speed pneumatic valves and small DC relays. Leakage current is 0.1 mA max; residual voltage is 1.5 V max.
Can the NX-OD5121-5 be used in a safety circuit?
No. The NX-OD5121-5 is marked SIL None and is not for safety functions. For emergency-stop output or a safety door switch on a NX-SL3300 / NX-SL3500 safety controller, use the G9SA-301 AC-DC24 safety relay or the NX-SOD400 safety output unit.
