Omron NX-OD6121-5 — 32-Pt NPN Output, MIL Connector
SKU: NX-OD6121-5USD 75.00
Omron NX-OD6121-5 NX-series 32-point NPN digital output, 12-24 VDC, 0.5 A/point, MIL40, 30 mm wide. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX-OD6121-5 is a 32-point NPN (sinking) digital output unit for the NX-series I/O platform, manufactured by Omron Corporation. Hengyixin Automation stocks this controller option board in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series I/O System brochure (R183).
It sinks 32 discrete 24 VDC loads at 0.5 A per point and 4 A per unit from a MIL40 connector (plug sold separately). ON/OFF response time is 0.1 ms max OFF-to-ON and 0.8 ms max ON-to-OFF. Omron's catalogue records Short-circuit protected outputs: FALSE for this unit. The refreshing method is selectable: Free-Run, Standard-speed synchronous, or full synchronous with the EtherCAT cycle.
The 30 mm wide housing mounts on any NX-series coupler: NX-EIC202 for EtherNet/IP, NX-ECC202 or NX-ECC203 for EtherCAT. Power consumption is 5.80 W max at 24 VDC. The XW2D-40G6 terminal block or XW2Z-xxxFF-L MIL40 cables (sold separately) convert the MIL40 to field wiring. The PNP sourcing version is the NX-OD6256-5. The 16-point MIL variant is the NX-OD5121-5.
Key Features
- NX-series 32-point NPN (sinking) digital output unit, 12 to 24 VDC rated, 0.5 A per point, 4 A per NX unit
- MIL40 connector (plug not included), 30 mm wide housing, 30 x 100 x 89.52 mm, 135 g, IP20
- ON/OFF response time 0.1 ms max OFF-to-ON and 0.8 ms max ON-to-OFF, no load short-circuit protection (per Omron's catalogue)
- Selectable Free-Run, Standard-speed synchronous, and synchronous I/O refreshing to match the EtherCAT cycle
- SKU: NX-OD6121-5
- Series: Omron NX-series I/O platform (NX-OD digital output family)
- Voltage: 12 TO 24 VDC
- I/O: 32 I/O
Best-Fit Applications
- High-density solenoid bank on a 32-valve pneumatic manifold where the MIL40 cables land on a single XW2D-40G6 terminal block
- Indicator-light stack on a multi-station assembly line where 32 PNP-driven 24 VDC beacons switch in sync with the EtherCAT cycle
- Spare replacement on a press line where the previous NX-OD6121 (screw terminal) is swapped for the MIL40 connector version to free panel space
Buying Checklist
- Pick the NX-OD6121-5 for a 32-point NX-series NPN output unit with a MIL40 connector on the 30 mm wide housing.
- Pick the NX-OD6256-5 instead when the field devices are PNP (sourcing) and the cabinet needs a sourcing 32-point output on the same MIL40 housing.
- Pick the NX-OD5121-5 instead when the panel only needs 16 outputs on the same MIL40 connector and the same 30 mm wide housing.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron NX-series I/O platform (NX-OD digital output family) |
| Model / SKU | NX-OD6121-5 |
| Number of Points | 32 NPN (sinking) digital outputs, 1-wire connection per output |
| Rated Voltage | 12 to 24 VDC (allowable voltage fluctuation 15.0 to 28.8 VDC at the output terminal) |
| Output Current | 0.5 A max per point, 4 A max per NX unit |
| Response Time | OFF-to-ON 0.1 ms max, ON-to-OFF 0.8 ms max at 24 VDC, 70 percent of rated load |
| Output Protection | Omron's catalogue records Short-circuit protected outputs: FALSE; residual voltage 1.5 V max, leakage current 0.1 mA max |
| I/O Refreshing | Free-Run refreshing, Standard-speed synchronous I/O refreshing, synchronous I/O refreshing (selectable per project) |
| I/O Connector | MIL40 connector (plug not included), 4 IOV (V+) and 4 IOG (V-) terminals, mating cable XW2Z-xxxFF-L or terminal block XW2D-40G6 |
| Isolation | Photocoupler isolation between field outputs and NX internal bus, 500 VAC for 1 minute |
| Power / Environment | 5.80 W max from NX bus at 24 VDC, 30 (W) x 100 (H) x 89.52 (D) mm, 135 g, IP20, 0 to +55 C operating, cULus / CE / KC / RCM listed |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NX-OD6121-5
What is the Omron NX-OD6121-5 used for?
It is the NX-series 32-point NPN (sinking) digital output unit with a MIL40 connector and a 30 mm wide housing. It mounts on the NX backplane and drives 32 discrete 24 VDC loads at 0.5 A per point from an EtherCAT or EtherNet/IP NX coupler. It is the typical drop-in for high-density solenoid banks, indicator stacks, and small relay racks on machines that already use the NX-series I/O platform.
NX-OD6121-5 vs NX-OD6256-5 - what is the difference?
Both share the same 32-point body, MIL40 connector, and 30 mm wide housing. The -6121 is NPN (sinking); the -6256 is PNP (sourcing). Pick the -6121 for European-style NPN wiring where the load is tied to 24 VDC and the output switches the return side. Pick the -6256 for PNP wiring where the output sources 24 VDC to the load.
Does the NX-OD6121-5 work with synchronous I/O?
Yes. The NX-OD6121-5 supports Free-Run refreshing, Standard-speed synchronous I/O refreshing, and synchronous I/O refreshing matched to the EtherCAT cycle. Set the refreshing mode in the Sysmac Studio I/O Map for the unit. Free-Run is the typical default; switch to synchronous when the outputs must move in step with the encoder or the servo cycle.
What NX coupler works with the NX-OD6121-5?
Any of the NX-series communication couplers. For EtherNet/IP, use the NX-EIC202. For EtherCAT, use the NX-ECC202 or NX-ECC203. Up to 63 NX-OD6121-5 units (2,016 digital outputs) can sit on one NX-ECC203, limited by the coupler's power budget and the 30 mm slot count.
