Omron NX-OD6256-5 — 32-Pt PNP Output, MIL40
SKU: NX-OD6256-5USD 128.00
Omron NX-OD6256-5 NX-series 32-point PNP output, MIL40 connector, 30 mm wide, Free-Run or Sync refresh. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX-OD6256-5 is the NX-series 32-point PNP transistor output unit, manufactured by Omron Corporation. Hengyixin Automation stocks this controller option board in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. Specifications on this page were checked against Omron's NX-series I/O System brochure (R183).
It delivers 32 PNP sourcing outputs at 0.5 A per point, 2 A per common, and 4 A per unit from a 24 VDC load supply (20.4 to 28.8 VDC). Maximum inrush is 4.0 A per point for 10 ms. Residual voltage is 1.5 V max and leakage is 0.1 mA max. ON response is 0.5 ms max and OFF is 1.0 ms max.
I/O refresh can switch between Free-Run and Synchronous. The unit includes load short-circuit protection, four IOV (V+) and four IOG (V-) terminals, and photocoupler isolation to the NX bus. The 30 x 100 x 71 mm housing weighs 95 g. The MIL40 connector is sold separately; pair with an XW2Z MIL-to-Phoenix cable. The NPN sibling is the NX-OD6121-6. For 16 PNP outputs pick the NX-OD5256.
Key Features
- NX-series 32-point PNP transistor output unit with MIL40 connector (sold separately), 30 mm wide
- 0.5 A per point, 2 A per common, 4 A per unit, 24 VDC nominal (20.4 to 28.8 VDC operating range), load short-circuit protection
- ON 0.5 ms max, OFF 1.0 ms max, switchable Free-Run or Synchronous I/O refresh, photocoupler isolation
- NX Unit power 1.30 W max on CPU or Communication Control Unit, 1.00 W max on Communications Coupler Unit, IP20
- SKU: NX-OD6256-5
- Series: NX-series machine automation I/O, digital output family (NX-OD)
- Voltage: 24 VDC
- I/O: 16 points
Best-Fit Applications
- Valve manifold on a multi-station rotary indexer where the NX-OD6256-5 drives 32 pneumatic solenoid outputs from one NX drop instead of running 32 home-run wires
- Indicator and stack-light cluster on a packaging line where the NX-OD6256-5 feeds 24 VDC LED drivers to a Sysmac NJ501 over EtherCAT with synchronous refresh
- Spare replacement on an automotive welding line where a CJ1W-OD232 32-point output migrates onto the NX-OD6256-5 with the XW2Z-100K MIL40 cable kept
Buying Checklist
- Pick the NX-OD6256-5 for 32 PNP sourcing outputs on a MIL40 connector with load short-circuit protection and switchable Free-Run or Synchronous refresh.
- Pick the NX-OD6121-6 instead when the cabinet needs 32 NPN sinking outputs on a Fujitsu/OTAX connector at the same 30 mm width.
- Pick the NX-OD5256 instead when 16 PNP outputs on screwless push-in terminals (no MIL cable needed) are enough and the 32-point density is not required.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | NX-series machine automation I/O, digital output family (NX-OD) |
| Model / SKU | NX-OD6256-5 |
| I/O Configuration | 32 outputs, PNP transistor (sourcing), 2 commons (16 points per common) |
| Rated Voltage | 24 VDC nominal; operating load voltage range 20.4 to 28.8 VDC |
| Output Rating | 0.5 A per point, 2 A per common, 4 A per unit; max inrush 4.0 A/point for 10 ms; residual voltage 1.5 V max; leakage 0.1 mA max |
| Response Time | ON 0.5 ms max, OFF 1.0 ms max |
| I/O Refresh | Switchable between Synchronous I/O refreshing and Free-Run refreshing |
| Connector | MIL connector, 40 terminals (plug not included); 4 IOV (V+) terminals and 4 IOG (V-) terminals |
| Protection | With load short-circuit protection; no disconnection detection; photocoupler isolation between output and NX bus |
| Power | NX Unit power 1.30 W max on CPU or Communication Control Unit, 1.00 W max on Communications Coupler Unit; I/O supply current 80 mA max |
| Environment / Wiring | 0 to 55 C operating, 10 to 95 percent humidity (no condensation); 30 (W) x 100 (H) x 71 (D) mm; 95 g; 35 mm DIN rail mount; IP20; cULus, CE, RCM, KC, NK, LR approvals |
