Omron NX-PF0630 — NX I/O Power Feed, 4 A
SKU: NX-PF0630USD 20.00
Omron NX-PF0630 NX I/O power feed unit, 5-24 VDC input, 4 A I/O supply, push-in, 12 mm wide. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX-PF0630 is an Additional I/O Power Supply unit for the NX-series I/O bus, manufactured by Omron Corporation. Hengyixin Automation stocks this power supply in Xiamen and ships within 3-5 business days in original Omron packaging. Specifications on this page were checked against Omron's NX-series System Unit datasheet.
The unit injects extra current into the I/O power rail of an NX rack. Input voltage is 5 to 24 VDC (operating 4.5 to 28.8 VDC). The I/O power feed max current is 4 A. This raises the available I/O power above what the CPU or EtherCAT coupler can deliver, or splits the rack into two isolated power groups for E-stop zoning.
The screwless push-in 8-terminal connector takes two IOV (+) and two IOG (-) pairs plus through-wiring for the next unit. The 12 x 100 x 71 mm body weighs 65 g and slots onto the NX bus like any other NX unit. Operating temperature is 0 to 55 degC. For a 10 A version on the same body, pick the NX-PF0730. For the NX-bus (unit) power supply role, use NX-PD1000.
Key Features
- NX-series Additional I/O Power Supply unit, 5-24 VDC input
- I/O power feed up to 4 A, 4.5 to 28.8 VDC operating range
- Screwless push-in 8-terminal connector, 12 x 100 x 71 mm
- Splits the I/O power supply into two groups along the NX bus
- SKU: NX-PF0630
- Series: Omron NX-series System Unit (Additional I/O Power Supply)
- Voltage: 5 TO 24 VDC
- I/O: 4 I/O
Best-Fit Applications
- Splitting a 32-station NX I/O rack into a hot zone (24 V always on) and a cold zone (dropped on E-stop) without a second CPU
- Adding 4 A of I/O current to a CX-series NX-ECC201 coupler whose 4 A internal limit has been reached by the digital output modules
- Spare replacement on a machine retrofit where the original NX-PF0630 failed and the new unit drops onto the same DIN-rail slot with no rewiring
Buying Checklist
- Pick the NX-PF0630 for a 4 A I/O power feed on an NX rack with a screwless push-in connector.
- Pick the NX-PF0730 instead when the I/O power feed needs 10 A on the same body.
- Pick the NX-PD1000 instead when the unit needs to feed the NX-bus (unit) 5 VDC rail rather than the I/O 24 VDC rail.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron NX-series System Unit (Additional I/O Power Supply) |
| Model / SKU | NX-PF0630 |
| Type of Module | I/O power feed / power connection |
| Power Supply Voltage | 5 to 24 VDC (4.5 to 28.8 VDC operating) |
| I/O Power Feed Max Current | 4 A |
| I/O Connection | Screwless push-in, 8 terminals (4 IOV + 4 IOG) |
| Isolation | No isolation between input and bus |
| NX Unit Power Consumption | 0.85 W max (from NX bus) |
| Operating Temperature | 0 to 55 degC |
| Protection | IP20 |
| Dimensions / Weight | 12 (W) x 100 (H) x 71 (D) mm; 65 g |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NX-PF0630
Where do I place the NX-PF0630 in the rack?
Anywhere after the CPU or EtherCAT coupler. The NX-PF0630 has no address of its own; it sits on the bus as a power unit. Place it between two I/O groups when you want to split the I/O power.
Does the NX-PF0630 add EtherCAT nodes?
No. The unit has no EtherCAT slave interface. It is invisible on the network configuration. The I/O modules on either side count as one rack on the network.
Can I parallel two NX-PF0630 units?
Not for current sharing on the same group. Use two NX-PF0630 units only when you want to split the rack into two isolated power groups.
