Omron NX-PF0730 — front face of the NX-series I/O power feed unit showing the 12 mm wide white housing with the TS indicator on the upper left, the green NX-bus connector on the lower left that mates to the adjacent NX unit, the detachable 8-position screwless push-in terminal block on the right with 4 IOV (V+) and 4 IOG (V-) markings and the NX-PF0730 model label on the upper right

Omron NX-PF0730 — NX I/O Power Feed, 12 mm

SKU: NX-PF0730

USD 22.00

Omron NX-PF0730 NX I/O power feed unit, 5-24 VDC input, 10 A out, 12 mm wide. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NX-PF0730 is the NX-series I/O power feed unit, manufactured by Omron Corporation. Hengyixin Automation stocks this controller option board in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

It injects a fresh 5 to 24 VDC power segment into an NX I/O rack at up to 10 A. The unit carries 4 IOV (V+) terminals and 4 IOG (V-) terminals on a detachable screwless push-in terminal block. The IOG terminals are internally bridged so the cable lands once and feeds the downstream segment.

Use it to break a long NX rack into separate I/O power segments so the downstream units do not share the CPU or Coupler Unit's I/O power budget. The body is 104.5 x 12 x 80.1 mm and weighs 65 g. Siblings are the NX-PF0630 (6 A) and the NX-PD1000 system PSU. For CP1L expansion look at the CP1W-EXT01.

Key Features

  • NX-series I/O power feed unit with screwless push-in connector and detachable 8-position terminal block, 12 mm wide
  • 5 to 24 VDC input, 10 A output current, 4 IOV (V+) terminals and 4 IOG (V-) terminals internally bridged
  • Inserts a fresh 24 VDC segment into a long NX I/O rack so downstream units do not share upstream I/O power budget
  • IP20, 104.5 (H) x 12 (W) x 80.1 (D) mm, 65 g, DIN-rail mount, CE and cULus approvals
  • SKU: NX-PF0730
  • Series: NX-series machine automation I/O, system unit family (NX-PF)
  • Voltage: 5 TO 24 VDC

Best-Fit Applications

  • Mid-rack I/O power feed on a 12-unit NX slice line where the upstream CPU budget is exhausted and a second 24 VDC segment is needed
  • Spare segment for a Sysmac NJ501 EtherCAT rack where the original NX-PF0730 was lost during a maintenance swap and the downstream NX-OD4256 needs isolated power
  • Spare replacement for a CJ1W-PA202 retrofit where the new NX rack needs an NX-PF0730 to share the same 24 VDC cabinet feed

Buying Checklist

  • Pick the NX-PF0730 when 10 A of fresh I/O power is needed in an NX rack segment and 12 mm of DIN width is acceptable.
  • Pick the NX-PF0630 instead when the segment only needs 6 A of I/O power and the same 12 mm form factor is preferred.
  • Pick the NX-PD1000 instead when the rack needs a dedicated 24 VDC system power supply feeding the NX bus itself, not just the I/O segment.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series NX-series machine automation I/O, system unit family (NX-PF)
Model / SKU NX-PF0730
I/O System NX I/O Bus
Type of Module Power feed (I/O power supply feed)
Input Voltage 5 to 24 VDC (24 VDC +10 percent / -15 percent typical)
Output Current 10 A maximum per unit
Terminals 4 IOV (V+) terminals and 4 IOG (V-) terminals; IOG internally bridged
Connector Screwless push-in, 1 detachable 8-position I/O terminal block
Protection IP20; no safety function (SIL according to IEC 61508: none)
Power / Isolation NX Unit power consumed from the NX bus only; 0 V terminals internally connected
Environment / Wiring 0 to 55 C operating; 104.5 (H) x 12 (W) x 80.1 (D) mm; 65 g unpacked; DIN 35 mm rail mount; cULus, CE, RCM, KC, NK, LR approvals

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for NX-PF0730

What is the Omron NX-PF0730 used for?
It is the NX-series I/O power feed unit. It injects a fresh 5 to 24 VDC segment into a long NX I/O rack at up to 10 A, so downstream NX units do not share the upstream CPU or Coupler Unit's I/O power budget. Typical uses are mid-rack I/O power segments on a 12-unit slice line, spare segments on a Sysmac NJ501 EtherCAT rack, and CJ1W-PA202 retrofits that need to add isolated 24 VDC to a new NX rack.
NX-PF0730 vs NX-PF0630 - what is the difference?
Both are 12 mm wide NX I/O power feed units with the same terminal layout. The NX-PF0730 supplies up to 10 A; the NX-PF0630 supplies up to 6 A. Pick the NX-PF0730 when the downstream segment has high-current outputs (NX-OD4121 PNP at 0.5 A per point) or a stack of analog units; pick the NX-PF0630 when the segment only has a few low-current slices.
Does the NX-PF0730 supply the NX bus itself?
No. The NX-PF0730 supplies the I/O power segment only (4 IOV and 4 IOG terminals). The NX bus power is supplied by the System Unit such as the NX-PD1000. Use the NX-PF0730 to add a fresh I/O power segment; use the NX-PD1000 or NX-PF0630 if you also need to feed the NX bus itself.
