Omron NX1W-CIF01 — NX1 RS-232C Option Board
SKU: NX1W-CIF01USD 13.50
Omron NX1W-CIF01 NX1 RS-232C option board, 15 m, Host Link + Modbus-RTU. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX1W-CIF01 is a serial communications option board for the NX1P2-series compact PLC, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
The board adds one RS-232C port on a 9-terminal screwless clamping terminal block to an NX1P2 CPU. Maximum cable run is 15 m. Baud rates cover 1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6, and 115.2 kbps on a half-duplex, start-stop synchronized link. Supported protocols are Host Link (SYSMAC WAY), Modbus-RTU master, and no-protocol.
The board drops into Option Board Slot 1 (left) or Slot 2 (right) of any NX1P2 CPU unit. Power draw is counted against the host CPU's total. There is no 5 V supply terminal, so the NX1W-CIF01 cannot drive an external CJ1W-CIF11 or NT-AL001 converter. For RS-422A/485 use the NX1W-CIF11 (non-isolated, 50 m) or NX1W-CIF12 (isolated, 50 m). Programming is in Sysmac Studio.
Key Features
- NX1 series serial communications option board, 1 RS-232C port on a 9-terminal screwless clamping terminal block
- Half-duplex start-stop synchronization, 15 m max, 1.2 to 115.2 kbps baud rates, no 5 V output
- Host Link (SYSMAC WAY), Modbus-RTU master, and no-protocol communication on the NX1P2 option-board slot
- Fits NX1P2 Slot 1 (left) or Slot 2 (right); 35.9 x 35.9 x 13.5 mm, 16 g, no isolation
- SKU: NX1W-CIF01
- Series: Omron NX1W series option board (for NX1P2 compact PLC CPU)
Best-Fit Applications
- Barcode reader integration on a small conveyor where the NX1P2 needs an RS-232C port to read 1D codes at the infeed station
- Serial temperature controller polling where the NX1W-CIF01 hosts Modbus-RTU master to scan four E5CC controllers every 250 ms
- Spare replacement on a legacy machine where the built-in RS-232C on the NX1P2 is already used for the touch panel HMI
Buying Checklist
- Pick the NX1W-CIF01 for a single RS-232C port on an NX1P2 compact PLC at 15 m or less, with no isolation required.
- Pick the NX1W-CIF11 instead when the device uses RS-422A/485 and runs up to 50 m on non-isolated wiring.
- Pick the NX1W-CIF12 instead when the cabinet needs isolated RS-422A/485 to break ground loops between the PLC and field devices.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron NX1W series option board (for NX1P2 compact PLC CPU) |
| Model / SKU | NX1W-CIF01 |
| Communication Port | 1 x RS-232C, D-sub / 9-terminal screwless clamping terminal block |
| Communication Method | Half-duplex, start-stop synchronization |
| Baud Rate | 1.2 / 2.4 / 4.8 / 9.6 / 19.2 / 38.4 / 57.6 / 115.2 kbps |
| Maximum Cable Length | 15 m |
| Supported Protocols | Host Link (SYSMAC WAY), Modbus-RTU master, no-protocol |
| Applicable Wire Size | AWG 28 to 20 |
| Isolation | No isolation between RS-232C line and ground (terminals isolated from CPU internal circuits only) |
| Dimensions / Weight | 35.9 (W) x 35.9 (H) x 13.5 (D) mm, 16 g |
| Power / Environment | Drawn from NX1P2 CPU power budget (no separate supply), 0 to 55 C operating |
FAQ for NX1W-CIF01
What is the Omron NX1W-CIF01 used for?
It is a serial communications option board for the NX1P2 compact PLC. The single RS-232C port is used to connect barcode readers, serial temperature controllers, or other legacy serial field devices that do not require isolation.
NX1W-CIF01 vs NX1W-CIF11 - what is the difference?
The NX1W-CIF01 is RS-232C with a 15 m max cable. The NX1W-CIF11 is non-isolated RS-422A/485 with a 50 m max cable. Pick the 232C for short point-to-point serial and the 11 for multi-drop RS-485 networks.
Is the NX1W-CIF01 isolated?
No. The terminals are isolated from the CPU internal circuits, but the RS-232C line itself shares ground with the CPU. For an isolated option use the NX1W-CIF12 (isolated RS-422A/485).
Which NX1P2 slot fits the NX1W-CIF01?
Option Board Slot 1 (left) or Slot 2 (right) on any NX1P2 CPU unit. Up to two option boards can be installed in parallel, so a second serial port is possible with the NX1P2's two slots.
Can the NX1W-CIF01 supply 5 V to a downstream converter?
No. There is no 5 V output terminal on the NX1W-CIF01, so it cannot drive an external CJ1W-CIF11 / NT-AL001 RS-232C-to-RS-485 converter or NV3W-M[]20L PT.
