Omron R88D-1SN30H-ECT-06 — front face of the 1S 3 kW EtherCAT drive showing the charge / power LEDs, the two EtherCAT RJ45 ports at the upper left, the safety input terminal block at the upper right and the R88D-1SN30H-ECT-06 type label

Omron R88D-1SN30H-ECT-06 — 3 kW 1S Servo Drive

SKU: R88D-1SN30H-ECT-06

USD 485.00

1S EtherCAT servo drive, 3 kW, 200-240 VAC, with motor cable set. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron R88D-1SN30H-ECT-06 is a 1S-series EtherCAT servo drive with a bundled motor cable set It is manufactured by Omron Corporation. Hengyixin Automation ships this drive from Xiamen with the matching motor or PSU pairing recommended in the related products row below. The drive delivers 3 kW rated output from a 200-240 VAC single-phase or 3-phase supply. Rated current is 15.9 A, rated output current 22.3 A rms, and maximum output current 54.7 A rms. For the 400 VAC class at 1 kW in the same family, pick the R88D-1SN10F-ECT; for the same 3 kW drive without the cable bundle, the R88D-1SN08H-ECT. Key specs: Rated Output 3 kW (3000 W); Main Supply 200 to 240 VAC single-phase or 3-phase (170 to 252 VAC operating), 50/60 Hz; Control Supply 24 VDC (21.6 to 26.4 V); Rated Current 15.9 A input / 22.3 A rms output / 54.7 A rms peak output; Heat Generation Main circuit 167.5 W, control circuit 20.4 W; Safety Hardwired STO PLe SIL3 + network STO via EtherCAT PLd SIL2 (EN ISO 13849-1 / IEC 61508 / EN 61800-5-2); Encoder / Motor Pair R88M-1M3K030H-S2 / R88M-1M3K030T-S2 with 23-bit battery-free.

Key Features

  • 1S-series EtherCAT servo drive, 3 kW rated output, 200-240 VAC single-phase or 3-phase supply
  • Hardwired STO PLe SIL3 plus network STO via EtherCAT PLd SIL2 (EN ISO 13849-1 / IEC 61508)
  • 23-bit battery-free absolute encoder, embedded motor-brake relay, screw-less push-in connectors
  • -06 includes a matching motor cable set for direct install, programming via Sysmac Studio
  • SKU: R88D-1SN30H-ECT-06
  • Series: Omron 1S-series EtherCAT AC servo drive

Best-Fit Applications

  • High-cycle rotary indexing table on a packaging line where 3 kW of drive power drives a heavy puck conveyor with sub-millisecond settle
  • Material-handling gantry where a single NJ / NX controller synchronises three R88D-1SN drives over EtherCAT for coordinated motion
  • Spare replacement on a retrofit where the previous 1S drive failed and the matching -06 cable set avoids ordering a second BOM line

Buying Checklist

  • Pick the R88D-1SN30H-ECT-06 for a 3 kW 1S EtherCAT drive with a bundled motor cable set.
  • Pick the R88D-1SN30F-ECT instead when the cabinet needs a 400 VAC 3-phase supply without the cable bundle.
  • Pick the R88D-1SN20H-ECT-06 instead when the application needs 2 kW with the same cable bundle.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron 1S-series EtherCAT AC servo drive
Model / SKU R88D-1SN30H-ECT-06
Rated Output 3 kW (3000 W)
Main Supply 200 to 240 VAC single-phase or 3-phase (170 to 252 VAC operating), 50/60 Hz
Control Supply 24 VDC (21.6 to 26.4 V)
Rated Current 15.9 A input / 22.3 A rms output / 54.7 A rms peak output
Heat Generation Main circuit 167.5 W, control circuit 20.4 W
Safety Hardwired STO PLe SIL3 + network STO via EtherCAT PLd SIL2 (EN ISO 13849-1 / IEC 61508 / EN 61800-5-2)
Encoder / Motor Pair R88M-1M3K030H-S2 / R88M-1M3K030T-S2 with 23-bit battery-free absolute encoder
Connectors Screw-less push-in, embedded motor-brake relay, EtherCAT IN / OUT ports
Bundle / Environment -06 includes motor cable set, IP20 (IP54 panel-internal), 0 to 55 C, ~3.4 kg, 90 (W) x 180 (H) x 225 (D) mm

FAQ for R88D-1SN30H-ECT-06

What is the difference between R88D-1SN30H-ECT and R88D-1SN30H-ECT-06?
Both are 3 kW 1S-series 200-240 VAC EtherCAT drives with identical electrical specs. The -06 suffix bundles a matching R88M-1-series motor cable set (power + encoder + brake) so the drive arrives with the cables needed to install.
What safety functions does the R88D-1SN30H-ECT-06 have?
Hardwired STO (Safe Torque Off) to PLe SIL3 via EN ISO 13849-1 / IEC 61508 / EN 61800-5-2 when wired directly. Network STO via EtherCAT to PLd SIL2 when commanded by the controller. Both stop the motor's torque output safely; the drive does not include SS1, SLS, or SDI.
Which motor pairs with the R88D-1SN30H-ECT-06?
The R88M-1M3K030H-S2 (without brake) or the R88M-1M3K030T-S2 (with brake). Both carry the 23-bit battery-free absolute encoder that the 1S drive expects. The -06 cable set matches the 3 kW-class motor power, encoder, and brake leads.
Can the R88D-1SN30H-ECT-06 run from a 400 VAC supply?
No. The H-suffix drive is rated for 200-240 VAC single-phase or 3-phase. For 400 VAC 3-phase at the same 3 kW output, pick the R88D-1SN30F-ECT without the cable bundle, or the R88D-1SN30F-ECT-06 with the cable set.
How is the R88D-1SN30H-ECT-06 programmed?
All 1S drives are configured through Sysmac Studio on the same NJ / NX motion controller or PC tool connection. EtherCAT node ID, motor selection, gain tuning, and safety configuration are all done in the Sysmac Studio Servo Drive editor.
