Omron S8VK-C24024 — 240 W 24 VDC, 10 A Eco
SKU: S8VK-C24024USD 36.00
Omron S8VK-C24024 economy DIN-rail PSU, 240 W 24 VDC 10 A, 100-240 VAC input. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron S8VK-C24024 is a 240 W economy DIN-rail switch-mode power supply in the S8VK-C family, manufactured by Omron Corporation. Hengyixin Automation stocks this controller option board in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
The supply accepts single-phase 100-240 VAC at 50/60 Hz and delivers a regulated 24 VDC at 10 A continuous. The C family is the cost-down tier in the S8VK line, with no power-boost function and a narrower operating temperature range than the S8VK-G. Operating temperature is -25 to 60 C ambient with no derating.
The covered enclosure measures 60 mm W x 125 mm H x 150 mm D and weighs 800 g. Single set of DC output terminals. Compliance covers UL 508, EN 61204-3, CE, and RoHS. The S8VK-G24024 is the higher-spec general-purpose alternative at the same 240 W.
Key Features
- Economy single-phase 100-240 VAC DIN-rail PSU in the S8VK-C cost-down tier
- 240 W output, 24 VDC at 10 A continuous, no power-boost rating
- Operates from -25 to 60 C ambient, single set of DC output terminals
- 60 mm W x 125 mm H x 150 mm D, 800 g, UL 508 EN 61204-3 CE RoHS
- SKU: S8VK-C24024
- Series: S8VK-C economy DIN-rail power supply
- Voltage: 24 VDC
Best-Fit Applications
- Cost-sensitive cabinet where 240 W covers the PLC, HMI, and a small I/O slice and the S8VK-C economy tier saves 25 percent over S8VK-G
- Single-phase machine cell where -25 to 60 C ambient temperature matches the cabinet environment and no power boost is needed
- Spare replacement on a packaging machine where the original S8VK-C24024 failed and the same economy tier keeps the cabinet price intact
Buying Checklist
- Choose the S8VK-C24024 when the cabinet needs 240 W / 10 A at 24 VDC and the C economy tier is acceptable.
- Choose the S8VK-G24024 instead when the cabinet needs the same 240 W but with -40 to 70 C operation and 120 percent power boost.
- Choose the S8VK-T24024 instead when the cabinet has three-phase 380-480 VAC and needs 240 W at 24 VDC.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | S8VK-C economy DIN-rail power supply |
| Model / SKU | S8VK-C24024 |
| Output Power | 240 W |
| Output Voltage / Current | 24 VDC at 10 A continuous; no power-boost rating |
| Input Voltage | Single-phase 100-240 VAC, 50/60 Hz; 90-350 VDC |
| Operating Temperature | -25 to 60 C ambient, no derating |
| Mounting | DIN rail (TS35/7.5 or TS35/15), covered enclosed case |
| Parallel / Series Operation | Single set of DC output terminals |
| Protection | Overload, overvoltage, input surge, output short-circuit |
| Certifications | UL 508 listed, EN 61204-3, CE, RoHS |
| Dimensions / Weight | 60 mm W x 125 mm H x 150 mm D, 800 g |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for S8VK-C24024
What is the difference between S8VK-C24024 and S8VK-G24024?
Both are 240 W / 10 A 24 VDC DIN-rail supplies. The C suffix is the economy tier with no power boost and a -25 to 60 C operating range; the G suffix is the general-purpose tier with 120 percent power boost and -40 to 70 C range. Choose C when the cabinet is climate-controlled and no boost is needed, G for wider operating envelope.
Does the S8VK-C24024 accept DC input?
Yes. The supply accepts 90-350 VDC at the input terminals. This lets it ride on a DC bus or backup-battery system for short-term ride-through. The 24 VDC output remains regulated. The supply accepts 90-350 VDC at the input terminals, which lets it ride on a DC bus or backup-battery system for short-term ride-through during AC mains dropouts.
Can the S8VK-C24024 supplies run in parallel?
The S8VK-C has a single set of DC output terminals and is not designed for parallel operation. For redundant power, step up to the S8VK-G24024, which has dual output terminals and supports parallel operation. The C family is the cost-down tier in the S8VK line with no power-boost function, so the supply delivers its rated 10 A continuously without any temporary over-current capability above the rating.
Is the S8VK-C24024 still in production?
Yes. The S8VK-C economy tier is in active production and is the cost-down option for the S8VK line. For new builds where the operating envelope is wider, consider the S8VK-G24024 general-purpose variant. For new builds where the wider operating envelope matters, consider the S8VK-G24024, which adds 120 percent power boost and a -40 to 70 C operating range for the same 240 W output.
