Omron S8VK-G24024 — 240 W 24 VDC DIN-Rail PSU, 10 A
SKU: S8VK-G24024USD 75.00
S8VK-G series 240 W 24 VDC / 10 A DIN-rail switch-mode power supply, single-phase 100-240 VAC input (also 90-350 VDC). 89% efficiency, 5-year warranty, parallel operation up to 2 units, spring-clamp terminal blocks. LED status indicator.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The S8VK-G24024 is the 240 W / 24 VDC / 10 A variant of Omron's S8VK-G-series industrial switch-mode power supplies, designed for DIN-rail mounting in control cabinets and delivering 24 VDC output to PLCs, sensors, valves, and other 24 VDC industrial loads. The input is universal: 100 to 240 VAC single-phase (operating range 85 to 264 VAC, 50/60 Hz) or 90 to 350 VDC (for DC-bus installations, e.g., marine / forklift-battery-input applications).
Where the S8VK-G24024 sits in the S8VK-G family
The S8VK-G family is Omron's long-warranty mid-range DIN-rail PSU family, splitting along two axes: power rating (15 / 30 / 60 / 120 / 240 / 480 W) and output voltage (5 / 12 / 24 / 48 VDC). The S8VK-G24024 (this SKU) is the 240 W / 24 VDC variant — the right pick for medium-load panels with a CP1L / CP2E / NX-controlled system and 10-30 small sensors / valves / motors. For smaller panels with < 30 W load, pick the S8VK-G01524 (15 W / 0.65 A) or S8VK-G06024 (60 W / 2.5 A).
Efficiency, parallel operation, and redundancy configurations
Efficiency is 89 % typical at full load (24 VDC / 10 A) — measured at 200 VAC input. The supply is rated for continuous full-load operation at 0 to +50 °C with derating to 75 % at +60 °C. Power factor correction is built-in (> 0.95 typical at full load), meeting EN 61000-3-2 harmonic-distortion requirements for industrial installations. For redundant operation (N+1 where one supply can power the entire load if the other fails), the S8VK-G24024 supports parallel connection of up to 2 units with an external decoupling diode module (S8VK-G24024 + S8VK-G-PD2460 decoupling diode).
Terminal connections, form factor, and protection features
Input terminal: spring-cage or screw-type (5-conductor) at the bottom of the PSU — L, N, PE on AC; +V, 0 V, FG on DC. Output terminal: spring-cage or screw-type (4-conductor) at the top of the PSU — +V (× 2 for parallel), 0 V (× 2 for parallel), DC OK LED indicator (lights green when output > 80 % of nominal). The spring-clamp terminals accept 0.5 to 6 mm² wire (AWG 20 to 10) without the need for torque-screw verification on the output side — faster wiring than the S8VS screw terminals and equivalent connection reliability.
Key Features
- S8VK-G-series industrial DIN-rail switch-mode power supply
- Output 24 VDC nominal, adjustable 24.0 to 27.5 VDC via front-panel trimmer
- Output current 10 A continuous, 12 A peak for 5 s
- Input 100-240 VAC single-phase
- Input also accepts 90 to 350 VDC for DC-bus installations
- Efficiency 89 % typical at 200 VAC / full load — only 26 W waste heat
- Power factor > 0.95 at full load — meets EN 61000-3-2 harmonic distortion
- 5-year warranty — long-life industrial PSU
- SKU: S8VK-G24024
- Series: S8VK-G Industrial DIN-Rail Switch-Mode PSU
- Voltage: 24 VDC
- I/O: 24 I/O
Best-Fit Applications
- Primary 24 VDC supply for a CP1L-EM40DT1-D compact PLC system with 4 × CP1W-AD042 + CP1W-DA021 expansion — 240 W.
- NX-Bus industrial panel with NX-ECC202 coupler + 8 × NX-ID4142 + 6 × NX-OD4256 — the S8VK-G24024 provides both NX-Bus.
- Conveyor starter panel — 24 VDC supply for PLC + sensors, contactor coil interposing relays, indicator lamps; one S8VK-G24024 covers.
- Redundant N+1 power for a CP2E-N60DT1-D safety-monitored system — two S8VK-G24024 supplies in parallel via S8VK-G-PD2460 decoupling diode, so a.
Buying Checklist
- Pick S8VK-G24024 for 240 W 24 VDC / 10 A DIN-rail PSU with 5-year warranty — the standard pick for medium-sized CP1L / NX / 3G3MX2 panels
- Pick S8VK-G12024 for 120 W / 5 A panel with one or two NX-ECC couplers and modest I/O load
- Pick S8VK-G48024 for 480 W / 20 A large panel with multiple NX-ECC couplers and heavy I/O load
- Pick S8VK-G01524 for 15 W / 0.65 A small distributed panel — power for a few sensors and a low-end CP1L-with-serial
- Pick S8VK-C24024 for the cost-down 240 W PSU with 3-year warranty for cost-sensitive panels
- Pick S8VS-24024A for the legacy 240 W PSU — only for spare-parts replenishment of running systems
Technical Specifications
| Model | S8VK-G24024 |
|---|---|
| Series | S8VK-G Industrial DIN-Rail Switch-Mode PSU |
| Type | Single-phase AC / DC input, regulated 24 VDC output, DIN-rail mount |
| Power Rating | 240 W continuous (288 W peak for 5 s) |
| Output Voltage | 24 VDC nominal (adjustable 24.0 to 27.5 VDC via front-panel trimmer) |
| Output Current | 10 A continuous, 12 A peak (5 s, 50 % duty at 25 °C ambient) |
| Output Voltage Accuracy | ±1 % (24 VDC ±0.24 VDC) |
| Output Ripple | 60 mV p-p max (20 MHz BW) |
| Output Hold Time | 20 ms min at full load (after AC loss) |
| Input Voltage (AC) | 100 to 240 VAC nominal (85 to 264 VAC operating, 47 to 63 Hz) |
| Input Voltage (DC) | 90 to 350 VDC (for DC-bus installations) |
| Input Current | 2.7 A max at 100 VAC / full load (1.3 A at 200 VAC) |
| Inrush Current | 20 A peak at 100 VAC cold start (limited by NTC thermistor) |
| Protection: Over-voltage | Yes — latched shutdown at 130 % of nominal (31.2 VDC) — requires AC recycle |
| Protection: Over-temperature | Yes — heatsink > 110 °C shutdown (auto-restart after cooling) |
Resources & Downloads
FAQ for S8VK-G24024
What's the difference between S8VK-G24024 and S8VK-C24024?
Both are 240 W 24 VDC / 10 A DIN-rail PSUs from Omron, but they sit in different product families. The S8VK-G24024 (this SKU) is in the G-series — long-warranty mid-range (5-year warranty), high efficiency (89 % typical), integrated EMC Class B line filter, spring-clamp terminals for fast wiring. The S8VK-C24024 is in the C-series — cost-down mid-range (3-year warranty), lower efficiency (85 % typical), screw terminals, basic protection features.
Can two S8VK-G24024 supplies be paralleled for redundancy?
Yes — the S8VK-G24024 supports parallel operation of up to 2 units with the S8VK-G-PD2460 external decoupling diode module (the S8VK-G doesn't have active current-share, so the diode is required to prevent back-feeding when one supply fails). The configuration: each S8VK-G24024's +V and 0 V outputs go to one S8VK-G-PD2460 input channel each; the S8VK-G-PD2460's common output feeds the load.
What is DC OK signaling on the S8VK-G24024?
The DC OK signal is a status output that indicates whether the PSU's 24 VDC output is healthy (within regulation). On the S8VK-G24024, the DC OK signal is implemented as a green LED on the front face that lights when output is > 80 % of nominal voltage (i.e., above 19.2 VDC for 24 VDC nominal). The LED turns off if the PSU enters overload, over-voltage (latched), over-temperature, or any fault condition.
What's the difference between S8VK-G24024 and the older S8VS-24024A?
Functionally they're similar — both are 240 W 24 VDC / 10 A DIN-rail PSUs.
