Omron CJ2H-CPU66 — front face of the CJ2H CPU showing the LED status row (RUN, ERROR, INH, PRPHL), the RS-232C DB9 serial port, the USB mini-B programming port, the battery compartment at the lower left and the type label CJ2H-CPU66

Omron CJ2H-CPU66 — CJ2H CPU, 150K Steps, RS-232C

SKU: CJ2H-CPU66

USD 1200.00

Omron CJ2H-CPU66 CJ2H CPU, 150K-step program, 352K-word data memory, RS-232C + USB, 2560 I/O max. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CJ2H-CPU66 is a high-performance CPU unit from the CJ2H modular PLC platform, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

The CPU delivers 150 K steps of program capacity with 16 ns basic instruction execution and 100 us system overhead. Data memory totals 352 K words - 32 K words of DM plus 32 K words across 10 EM banks. Function block programming, structured text, and ladder are all supported. Built-in ports are RS-232C and USB for programming; the CPU does not have EtherNet/IP.

Up to three expansion racks host 40 expansion units and 2560 local I/O points. Power supply and CJ1W / CS1W expansion units are ordered separately; compatible supplies include CJ1W-PA202 14 W, CJ1W-PA205R 25 W, CJ1W-PD022 19.6 W, and CJ1W-PD025 25 W. The CJ2H-CPU66-EIP sibling adds EtherNet/IP on top of the same 150K-step program.

Key Features

  • CJ2H-series CPU, 150 K-step program, 352 K-word data memory (32 K DM + 32 K x 10 EM banks)
  • 16 ns basic instruction execution, 100 us system overhead, function block programming and structured text
  • Up to 40 expansion units across 3 racks, 2560 max local I/O points
  • RS-232C DB9 + USB programming ports (no EtherNet/IP on this CPU; use CJ2H-CPU66-EIP for Ethernet)
  • SKU: CJ2H-CPU66
  • Series: Omron CJ2H-series modular PLC CPU

Best-Fit Applications

  • Multi-rack packaging line where 150K steps hold recipes, alarm logs, and trend data for 8 to 10 machine stations
  • Retrofit of a CJ1G-CPU4xH panel where the CJ2H keeps the CJ1W I/O in place but adds FB/ST programming and faster scan
  • Mid-size process skid where the CJ2H-CPU66-EIP later adds EtherNet/IP for SCADA without changing the program

Buying Checklist

  • Pick the CJ2H-CPU66 for a 150K-step CJ2H CPU with RS-232C + USB on a serial-only architecture.
  • Pick the CJ2H-CPU66-EIP instead when the panel needs built-in EtherNet/IP on top of the same 150K-step program.
  • Pick the CJ2H-CPU64 instead when the program fits within 100K steps and the budget is tighter.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CJ2H-series modular PLC CPU
Model / SKU CJ2H-CPU66
Program Capacity 150 K steps (600 K bytes)
Data Memory 32 K words DM + 32 K words x 10 EM banks = 352 K words
Logic Execution 16 ns basic instruction, 100 us system overhead
Built-In I/O 0 digital I/O (CPU only - I/O comes from CJ1W units)
Expansion Up to 40 expansion units, 3 expansion racks, 2560 max local I/O points
Programming Ports RS-232C DB9 male + USB (no EtherNet/IP on this CPU)
Function Blocks / Languages Ladder, structured text, function block programming
Compatible Supplies CJ1W-PA202 14 W, CJ1W-PA205R 25 W, CJ1W-PD022 19.6 W, CJ1W-PD025 25 W
Dimensions (W x H x D) 48.8 × 90 × 74.5 mm; 190 g

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for CJ2H-CPU66

Does the CJ2H-CPU66 have built-in EtherNet/IP?
No. The CJ2H-CPU66 ships with RS-232C and USB ports only. For EtherNet/IP on the same 150K-step CPU, pick the CJ2H-CPU66-EIP. EtherNet/IP can also be added via a CJ1W-EIP21 unit on the same rack.
What power supply does the CJ2H-CPU66 need?
The CPU ships without a supply. Common matches are CJ1W-PA202 (100-240 VAC, 14 W) for small racks, CJ1W-PA205R (100-240 VAC, 25 W) for medium racks, CJ1W-PD022 (24 VDC, 19.6 W), and CJ1W-PD025 (24 VDC, 25 W).
What is the difference between CJ2H-CPU66 and CJ2H-CPU68-EIP?
The CPU66 has 150K-step program and serial-only ports. The CPU68-EIP raises the program to 400K steps and adds EtherNet/IP. Both are CJ2H high-performance CPUs and are program-compatible within the CJ2H series.
How much data memory does the CJ2H-CPU66 have?
352 K words total - 32 K words of DM plus 32 K words across 10 EM (extended memory) banks. Recipes, production counters, and alarm logs go into DM; large lookup tables and history go into EM.
How do I set up the CJ2H-CPU66 expansion rack?
Mount a CJ1W-IC101 I/O Control Unit on the right side of the CPU and a CJ1W-II101 I/O Interface Unit on each expansion rack, then connect them with a CS1W-CN223 (2 m) or CS1W-CN713 (70 cm) cable. Up to three racks are supported.
