Omron NS5-SQ10B-ECV2 — front face of the 5.7-inch NS-series HMI showing the 320 x 240 pixel TFT color display, the resistive touch panel, the black bezel with the Omron logo and the NS5-SQ10B-ECV2 type label on the upper bezel

Omron NS5-SQ10B-ECV2 — 5.7" HMI, LED Backlight, 60 MB

SKU: NS5-SQ10B-ECV2

USD 415.00

Omron NS5-SQ10B-ECV2 5.7-inch TFT color HMI, 320 x 240 QVGA, 60 MB memory, RS-232C, 24 VDC. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron NS5-SQ10B-ECV2 is the 5.7-inch TFT color HMI from the NS-series V2 platform with the upgraded LED backlight, manufactured by Omron Corporation. Hengyixin Automation ships this HMI panel from Xiamen with the Sysmac Studio or NB-Designer project file on a USB drive included.

The display shows 320 x 240 pixel QVGA graphics in 32,768 colors with an LED backlight rated 75,000 hours. The resistive touch panel reads CX-Designer screens. The 60 MB memory stores screens, alarm logs, recipes, and ladder monitor data. Two D-sub 9-pin RS-232C serial ports handle Host Link plus a secondary port for barcode readers.

Supply is 24 VDC at 15 W max, 20.4 to 27.6 VDC. Front face is IP65 / UL Type 4. Panel cutout is 184 mm x 131 mm. The unit is discontinued; the modern Sysmac Studio replacement is the NA5-7W001B-V1 on the same cutout. the SQ models carry an LED backlight rated 75,000 hours; the CCFL-to-LED change came with the -V2 generation, not between the SQ and TQ variants.

Key Features

  • NS-series 5.7-inch TFT color HMI, 320 x 240 pixel QVGA display, 32,768 colors, LED backlight rated 75,000 hours
  • 60 MB project memory for full screen sets, alarm logs, recipe tables, and ladder monitor data on the SD-card slot
  • Two D-sub 9-pin RS-232C serial ports (Serial A and Serial B), Host Link / NT Link / barcode reader protocols, no Ethernet
  • 24 VDC supply at 15 W max, 20.4 to 27.6 VDC allowed, IP65 / UL Type 4 front face, panel cutout 184 mm x 131 mm
  • SKU: NS5-SQ10B-ECV2
  • Series: Omron NS-series V2 programmable terminal (PT) / HMI
  • Voltage: 24 VDC

Best-Fit Applications

  • Operator panel for a packaging line where two units pair with a CP1L-EM30DT-D over Host Link and the ladder program is monitored from the screen
  • Spare replacement on a bottling line where the original CCFL-backlit NS5-SQ10B-V2 is dim and the LED-backlight ECV2 lands in the same cutout
  • Recipe-selection terminal on a multi-line oven where the operator scans a barcode on the Serial B RS-232C port and the recipe opens

Buying Checklist

  • Pick the NS5-SQ10B-ECV2 for a 5.7-inch TFT color HMI with 60 MB project memory and the long-life LED backlight on the NS-series V2 platform.
  • Pick the NS5-TQ10B-V2 instead when the cabinet needs the same 5.7-inch body in the high-luminance TQ variant.
  • Pick the NA5-7W001B-V1 instead when the panel needs the modern Sysmac Studio replacement with Ethernet on the same 184 x 131 mm cutout.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron NS-series V2 programmable terminal (PT) / HMI
Model / SKU NS5-SQ10B-ECV2
Display 5.7-inch TFT color LCD, 320 x 240 pixel QVGA, 32,768 colors, LED backlight, 75,000-hour service life
Touch Panel Resistive analog touch, 16 x 12 matrix
Memory 60 MB project memory for screens, alarms, recipes, and ladder monitor data
Serial Ports Serial A D-sub 9-pin RS-232C (Host Link / NT Link); Serial B D-sub 9-pin RS-232C (barcode / downstream)
USB Port USB Type-B slave for CX-Designer project upload / download
Power Supply 24 VDC, 20.4 to 27.6 VDC allowed (24 VDC plus or minus 15 percent), 15 W max consumption
Panel Cutout 184 mm wide x 131 mm high (per Omron NS5 installation guide)
Dimensions / Weight 142 (H) x 206.3 (W) x 54.8 (D) mm, approximately 1.0 kg
Protection / Software IP65 / UL Type 4 front face, 0 to +55 C operating, CX-Designer support tool, CE / UL listed

FAQ for NS5-SQ10B-ECV2

What is the Omron NS5-SQ10B-ECV2 used for?
It is the NS-series V2 5.7-inch TFT color HMI with the upgraded LED backlight (the EC suffix). It runs CX-Designer screens on 60 MB of project memory and talks to the host PLC over RS-232C on the D-sub 9-pin Serial A port. The resistive touch panel and IP65 front face suit washdown panels.
NS5-SQ10B-ECV2 vs NS5-SQ10B-V2 - what is the difference?
Both are the same 5.7-inch NS5-V2 body with RS-232C on Serial A and Serial B, 60 MB memory, and the 184 x 131 mm panel cutout. Omron's published NS5-V2 lineup lists the SQ and TQ types alike with an LED backlight rated 75,000 hours; the CCFL-to-LED change came with the -V2 generation. We could not find an Omron listing that documents a separate EC suffix, so confirm what the EC denotes on this unit before ordering it against a SQ10B-V2. Pick the ECV2 as the spare for an existing V2 install - the panel cutout and project file are identical.
Does the NS5-SQ10B-ECV2 have Ethernet?
No. The NS5-SQ10B-ECV2 has two D-sub 9-pin RS-232C serial ports and a USB Type-B port for project transfer, but no Ethernet port. Pick the NS5-TQ10B-V2 or NA5-7W001B-V1 when the panel must connect to the host PLC over Ethernet.
