Omron NX102-9000 — Sysmac NX1 CPU, 4 PTP Axes
SKU: NX102-9000USD 639.00
Sysmac NX1 modular CPU, 5 MB / 33.5 MB, EtherCAT + EtherNet/IP, 4 PTP axes. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX102-9000 is a Sysmac NX1 modular CPU with 5 MB of program memory and 33.5 MB of variable memory It is manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
The CPU runs sequence control, position control, and OPC-UA server functions on a single core. The built-in EtherCAT master supports up to 64 nodes with 4 PTP axes (no synchronous servo axes).
The NX102-1100 adds 4 servo axes, the NX102-1200 adds 8 servo axes. Key specs: Program Memory 5 MB; Variable Memory 33.5 MB (1.5 MB retained during power loss); Primary Task Cycle 1 ms minimum; Axes 0 synchronous axes, 4 PTP axes, 4 total axes; EtherCAT Built-in master, up to 64 nodes; EtherNet/IP Two ports, 64 CIP connections, plus Ethernet TCP/IP; OPC-UA Server Built-in, all models; NX I/O Bus Up to 32 slices on the side bus; 8,960 I/O points with NX-ECC203.
Key Features
- Sysmac NX1 modular CPU, 5 MB program memory and 33.5 MB variable memory
- Built-in EtherCAT master for up to 64 nodes and 4 PTP axes, 1 ms primary task cycle
- Two EtherNet/IP ports with 64 CIP connections plus an Ethernet TCP/IP port for OPC-UA
- Up to 32 NX I/O slices on the side bus, 8,960 I/O points with an NX-ECC203 coupler
- SKU: NX102-9000
- Series: Sysmac NX1 modular CPU
Best-Fit Applications
- Replacement for an older CP1L or CJ2 machine where the cabinet hosts 32 NX slices on the side bus with no coupler
- Small packaging line PLC where 4 PTP axes drive indexing tables and the dual EtherNet/IP port feeds HMI and MES traffic
- IIoT-enabled machine cell where the built-in OPC-UA server publishes machine data straight to SCADA without a gateway PC
Buying Checklist
- Choose the NX102-9000 when the cell needs sequence and OPC-UA but no synchronous servo axes and 4 PTP axes are enough.
- Choose the NX102-1100 instead when the line adds 4 synchronous servo axes on top of the 4 PTP axes.
- Choose the NX102-1200 instead when the cabinet needs 8 synchronous servo axes driven from the built-in EtherCAT master.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Sysmac NX1 modular CPU |
| Model / SKU | NX102-9000 |
| Program Memory | 5 MB |
| Variable Memory | 33.5 MB (1.5 MB retained during power loss) |
| Primary Task Cycle | 1 ms minimum |
| Axes | 0 synchronous axes, 4 PTP axes, 4 total axes |
| EtherCAT | Built-in master, up to 64 nodes |
| EtherNet/IP | Two ports, 64 CIP connections, plus Ethernet TCP/IP |
| OPC-UA Server | Built-in, all models |
| NX I/O Bus | Up to 32 slices on the side bus; 8,960 I/O points with NX-ECC203 |
| Dimensions / Weight | 66 x 100 x 100 mm, 470 g; 0 to 55 C ambient |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NX102-9000
What is the difference between NX102-9000 and NX102-1000?
Both are Sysmac NX1 modular CPUs with 5 MB program and 33.5 MB variable memory. The NX102-9000 has zero synchronous servo axes and 4 PTP axes. The NX102-1000 adds 2 synchronous servo axes. For a conveyor or logic-only cell with no servo drives, pick the NX102-9000; for a 2-servo pick-and-place cell, pick the NX102-1000.
How many NX I/O slices can I connect to the NX102-9000?
Up to 32 slices on the side bus for 1,024 local I/O points. With an NX-ECC203 EtherCAT coupler added to the network, the total scales to 400 slices and 8,960 I/O points. The HMC-SD291 SD card slot is used for project backup and data logging.
Does the NX102-9000 support motion control?
It supports up to 4 PTP (point-to-point) axes - enough for indexing tables, diverters, and basic positioning. It does not support synchronous interpolated motion, which requires the NX102-1000 or higher. For cam profiles or electronic gearing, move up to the NX102-1100 or NX102-1200.
What software does the NX102-9000 use?
Sysmac Studio version 1.30 or later. Programming languages are Ladder, Structured Text, and Function Block per IEC 61131-3. Connect over the EtherNet/IP port with a standard Cat 5e or higher cable. The SD card slot accepts the HMC-SD291 for project backup.
