Omron NX1P2-1040DT — Compact PLC, 40 I/O, NPN
SKU: NX1P2-1040DTUSD 355.00
Omron NX1P2-1040DT NX1P2 compact PLC, 40 I/O (24 in / 16 NPN out), 24 VDC, EtherCAT + EtherNet/IP. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NX1P2-1040DT is the NX1P2-series compact machine automation controller with 40 built-in digital I/O and NPN outputs, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
It runs on 24 VDC and combines a 1.5 MB program / 2 MB variables controller with EtherCAT master (2 synchronous servo axes max, 4 PTP axes max) and EtherNet/IP scanner (32 connections). Primary task cycle 2 ms. Built-in I/O: 24 DC inputs (PNP/NPN selectable) and 16 NPN (sinking) outputs at 0.5 A per point.
Two Ethernet ports (EtherCAT + EtherNet/IP), no USB, and two serial option board slots for NX1W-CIF01 (RS-232C), NX1W-CIF11 (RS-422/485), or NX1W-CIF12 (isolated RS-485). Up to 8 NX expansion units stack on the right; up to 16 remote I/O nodes over EtherCAT. The PNP sibling at the same 40 I/O body is NX1P2-1040DT1. The smaller 24-I/O variant is NX1P2-9024DT. For more axes step up to NX102-1200.
Key Features
- NX1P2-series compact machine automation controller with 40 built-in digital I/O: 24 DC inputs (PNP/NPN selectable) plus 16 NPN (sinking) transistor outputs at 0.5 A per point
- 1.5 MB program memory, 2 MB variables, 2 ms primary task cycle, EtherCAT master (2 synchronous servo axes max) plus EtherNet/IP scanner (32 connections)
- 2 Ethernet ports (EtherCAT + EtherNet/IP), 2 serial option board slots for NX1W-CIF01 / CIF11 / CIF12, real-time clock with 10-day backup at 40 C
- Up to 8 NX expansion units, up to 16 EtherCAT remote I/O nodes, 24 VDC supply, 148 x 100 x 71 mm, 650 g
- SKU: NX1P2-1040DT
- Series: NX1P2-series compact machine automation controller (NX1 CPU family)
- I/O: 40 points
Best-Fit Applications
- Four-axis packing machine where the NX1P2-1040DT runs 2 servo axes via EtherCAT and 2 PTP axes via pulse output
- Compact conveyor cell with 24 VDC sensors on the built-in DC inputs and an NB5Q-TW01B-V1 HMI on EtherNet/IP
- Spare replacement on a small machine where the original NX1P2-1040DT was lost and Sysmac Studio has the project backup
Buying Checklist
- Pick the NX1P2-1040DT when the panel needs 40 built-in I/O (24 in / 16 NPN out) on a single compact PLC with EtherCAT + EtherNet/IP.
- Pick the NX1P2-1040DT1 instead when the loads need 16 PNP (sourcing) outputs instead of 16 NPN (sinking) outputs on the same 40-I/O body.
- Pick the NX1P2-9024DT instead when the panel only needs 24 built-in I/O (14 in / 10 out) on a smaller, less expensive body.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | NX1P2-series compact machine automation controller (NX1 CPU family) |
| Model / SKU | NX1P2-1040DT |
| Built-in I/O | 40 points: 24 DC inputs (PNP or NPN selectable) + 16 NPN (sinking) transistor outputs |
| Output Rating | 0.5 A per point, 1.5 A per common at 24 VDC; load short-circuit protection on PNP variants only (not on this NPN -DT variant) |
| Program / Variables | 1.5 MB program memory; 2 MB variables memory; SD memory card slot |
| Motion / Cycle | Primary task cycle 2 ms; 2 EtherCAT synchronous axes max; 4 PTP axes max; 6 total axes |
| Communication Ports | 2 Ethernet (EtherCAT master + EtherNet/IP scanner, 32 connections); 0 USB; 2 serial option board slots (RS-232C / RS-422A / RS-485 via NX1W-CIF01 / CIF11 / CIF12) |
| Expansion | Up to 8 NX-series expansion units (digital I/O, analog I/O, position interface, load cell); up to 16 EtherCAT remote I/O nodes |
| Real-Time Clock | Built-in real-time clock; retention time 10 days at 40 C ambient (built-in capacitor) |
| Supply / Power | 24 VDC supply, operating range 20.4 to 28.8 VDC; supply via unit power terminals |
| Dimensions / Approvals | 100 (W) x 148 (H) x 71 (D) mm; 650 g; IP20; CE, cULus, RCM, KC, EAC; programming with Sysmac Studio Ver. 1.07 or higher |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for NX1P2-1040DT
What is the Omron NX1P2-1040DT used for?
It is the NX1P2-series compact machine automation controller with 40 built-in I/O (24 DC inputs + 16 NPN outputs). Typical uses are four-axis packing machines with 2 servo + 2 PTP axes, compact conveyor cells with 24 VDC sensors and an NB5Q HMI on EtherNet/IP, and spare replacement on a small machine where the Sysmac Studio backup is ready.
NX1P2-1040DT vs NX1P2-1040DT1 - what is the difference?
Both are NX1P2 compact controllers with 40 built-in I/O (24 in + 16 out). The 1040DT has NPN (sinking) transistor outputs that switch the low side of a load; the 1040DT1 has PNP (sourcing) outputs that switch the high side and add load short-circuit protection. Pick the 1040DT for NPN field devices; pick the 1040DT1 for PNP field devices or where load short-circuit protection is required.
How many motion axes does the NX1P2-1040DT control?
Up to 2 EtherCAT synchronous servo axes and 4 PTP axes (6 total). The 2 EtherCAT axes connect R88D-1SN02H-ECT or R88D-KN02H-ECT-Z servo drives and use Sysmac Studio motion control functions. The 4 PTP axes use pulse outputs from the built-in I/O or from an NX-PG0112 pulse output slice. For more axes (up to 8 servo) step up to NX102-1200.
Does the NX1P2-1040DT have USB and serial ports?
No USB. Two serial option board slots accept NX1W-CIF01 (RS-232C, 15 m max), NX1W-CIF11 (RS-422 / RS-485, 50 m max), or NX1W-CIF12 (isolated RS-422 / RS-485, 500 m max). Programming is over Ethernet from Sysmac Studio; the SD memory card slot holds the project backup.
